Home/Electrical/Switchgear/Residual Current Devices/Residual Current Circuit Breaker 3P+N | 63A 100mA | DIN Rail Mount by NHP

Trade Discount 25%

NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 63A 100mA Type S

Residual Current Circuit Breaker 3P+N | 63A 100mA | DIN Rail Mount by NHP

BRAND: NHP

SKU: DSRCD463100S

$785.10 List price: $1,042.50

+ −

30 Days Return Delivery Options

Residual current circuit breaker with 3 pole and neutral configuration, rated at 63A and 100mA—ideal for residential, commercial, and industrial safety. Built for enhanced protection, with easy DIN rail mounting.

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 63A 100mA Type S

Brand: NHP

SKU: DSRCD463100S

Alternatively Known As: RCCB, Residual Current Device, RCD, Circuit Breaker

Technical Specifications

Number of Poles: 4
Voltage Type: AC
Frequency: 50/60 Hz
Rated Current: 63 A
Rated Leakage Current: 100 mA
Min Service Voltage: 205 V
Max Rated Operation Voltage: 455 V
Rated Insulation Voltage: 440 V
Rated Impulse Withstand Voltage: 8 kV
Rated Fault Current: 10000 A
Electrical Life: 10000 cycles
Degree of Protection: IP20
Connectable Conductor Cross Section: 50-50 mm²
Mechanical Life: 20000 cycles
Operating Temperature: 55 °C
Ambient Temperature: -25-55 °C
Storage Temperature: 70 °C
Pollution Degree: 2
Dimensions (H x L x W): 86mm x 76mm x 72mm
Weight: 0.37 kg

Key Features

3 Pole and Neutral configuration for enhanced safety.
Rated current of 63A and leakage current of 100mA.
DIN rail mounting for easy installation.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices and retail spaces
Industrial: Machinery and equipment protection

Standards & Compliance

Complies with AS/NZS 3000 for electrical installation safety.

Environmental Benefits

Enhances electrical safety, reducing the risk of electrical fires and accidents.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 63A 100mA Type S is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.

DSRCD463100S-AU-RCCB-3P-and-N-72mm-Datasheet.pdf (DSRCD463100S-AU-RCCB-3P-and-N-72mm-Datasheet.pdf, 242 Kb) [Download]
