NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 80A 100mA Type A

Residual Current Circuit Breaker RCCB 3P+N | 80A 100mA | DIN Rail Mount by NHP

BRAND: NHP

SKU: DSRCD480100A

$859.60 List price: $1,141.40

+ −

30 Days Return Delivery Options

Residual current circuit breaker with 3 pole and neutral design, 80A rated current, and 100mA leakage—ideal for residential and commercial safety. Built for easy installation with DIN rail mounting, enhancing electrical safety.

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 80A 100mA Type A

Brand: NHP

SKU: DSRCD480100A

Alternatively Known As: RCCB, Residual Current Circuit Breaker, RCD

Technical Specifications

Number of Poles: 4
Voltage Type: AC
Frequency: 50/60 Hz
Rated Current: 80 A
Leakage Current Type: A
Rated Leakage Current: 100 mA
Min Service Voltage: 205 V
Max Rated Operation Voltage: 455 V
Rated Insulation Voltage: 440 V
Rated Impulse Withstand Voltage: 8 kV
Rated Fault Current: 10000 A
Electrical Life: 10000 cycles
Degree of Protection: IP20
Connectable Conductor Cross Section: 50-50 mm²
Mechanical Life: 20000 cycles
Operating Temperature: 55 °C
Ambient Temperature: -25-55 °C
Storage Temperature: 70 °C
Pollution Degree: 2
Dimensions (H x L x W): 86mm x 76mm x 72mm
Weight: 0.37 kg

Key Features

3 Pole and Neutral design for enhanced safety.
Rated current of 80A and leakage current of 100mA.
DIN rail mounting for easy installation.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices, retail spaces, and industrial applications

Standards & Compliance

Complies with AS/NZS 3000 for electrical safety standards.

Environmental Benefits

Enhances electrical safety, reducing the risk of electrical fires and accidents.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 80A 100mA Type A is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

DSRCD480100A-AU-RCCB-3P-and-N-72mm-Datasheet.pdf (DSRCD480100A-AU-RCCB-3P-and-N-72mm-Datasheet.pdf, 282 Kb) [Download]
