NHP DIN-T Residual Current Device Short Body w/ Overcurrent 10kA 40A 1Pole and N C Curve 30mA Type A

Residual Current Device 10kA 40A | 30mA Type A | DIN Rail Mount by NHP

BRAND: NHP

SKU: DSRCB4030A

$179.20 List price: $237.90

+ −

30 Days Return Delivery Options

Residual current device with 10kA short circuit capacity and 40A rated current—ideal for residential and commercial safety. Built for overload protection, with 30mA leakage detection and easy DIN rail installation.

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Device Short Body w/ Overcurrent 10kA 40A 1Pole and N C Curve 30mA Type A

Brand: NHP

SKU: DSRCB4030A

Alternatively Known As: RCD, RCBO, Residual Current Circuit Breaker, Earth Leakage Circuit Breaker

Technical Specifications

Rated Current: 40 A
Rated Voltage: 240 V
Rated Leakage Current: 30 mA
Frequency: 50/60 Hz
Rated Short Circuit Breaking Capacity: 10 kA
Voltage Type: AC
Trip Curve: C
Rated Impulse Withstand Voltage: 6 kV
Tripping Time: 40 ms
Min Service Voltage: 100 V
Max Operating Voltage: 255 V
Rated Residual Make Break Capacity: 6000 A
Number of Poles Total: 2
Electrical Life: 10000 cycles
Mounting Method: DIN rail (top hat rail) 35 mm
Degree of Protection: IP20
Number of Protected Poles: 1
Mechanical Life: 20000 cycles
Operating Temperature: -5-55 °C
Dimensions (H x L x W): 86mm x 68mm x 36mm
Weight: 0.25 kg

Key Features

10kA short circuit breaking capacity
40A rated current with 30mA leakage protection
C curve tripping for better protection against overloads
DIN rail mounting for easy installation

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices, retail spaces, and industrial applications

Standards & Compliance

Complies with AS/NZS 61009 for safety and performance standards.

Environmental Benefits

Enhances electrical safety, reducing the risk of electrical fires and accidents.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Device is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

DSRCB4030A-AU-RCBO-10kA-1P-and-N-36mm-Datasheet.pdf (DSRCB4030A-AU-RCBO-10kA-1P-and-N-36mm-Datasheet.pdf, 279 Kb) [Download]
