Residual Current Device 6kA 25A | 30mA Type AI | Compact DIN Rail by NHP
Residual current device with 6kA short circuit capacity and 30mA residual current rating—ideal for residential and commercial safety. Built for enhanced protection, with compact design for DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Residual Current Device Short Body w/ Overcurrent 6kA 25A 1Pole and N C Curve 30mA Type AI
Brand: NHP
SKU: DSRCB2530AI
Alternatively Known As: RCD, RCBO, Residual Current Circuit Breaker, Earth Leakage Circuit Breaker
Technical Specifications
- Rated Current: 25 A
- Rated Voltage: 240 V
- Rated Leakage Current: 30 mA
- Frequency: 50/60 Hz
- Rated Short Circuit Breaking Capacity: 6 kA
- Voltage Type: AC
- Trip Curve: C
- Rated Impulse Withstand Voltage: 6 kV
- Tripping Time: 40 ms
- Min Service Voltage: 117 V
- Max Operating Voltage: 255 V
- Rated Residual Make Break Capacity: 6000 A
- Protected Neutral Pole: Yes
- Number of Poles Total: 2
- Electrical Life: 10,000 cycles
- Type of Electric Connection: Fork and pin
- Isolator Application: Yes
- Rated Insulation Voltage: 440 V
- Concurrently Switching Neutral Conductor: Yes
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Number of Protected Poles: 2
- Mechanical Life: 20,000 cycles
- Max Shock Duration: 5 ms
- Max Shock Acceleration: 40 g
- Max Vibration Acceleration: 1.5 m/s²
- Max Vibration Frequency Operational: 80 Hz
- Max Vibration Duration: 30 min
- Operating Temperature: -5 to 55 °C
- Dimensions (H x L x W): 86mm x 68mm x 36mm
- Weight: 0.25 kg
Key Features
- 6kA short circuit breaking capacity
- 30mA residual current rating for enhanced safety
- Compact design for DIN rail mounting
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring electrical safety
Standards & Compliance
- Complies with AS/NZS 61009 for safety and performance standards.
Environmental Benefits
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Residual Current Device Short Body w/ Overcurrent 6kA 25A 1Pole and N C Curve 30mA Type AI is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
