NHP DIN-T Residual Current Device Short Body w/ Overcurrent 6kA 40A 1Pole and N C Curve 30mA Type Ai

Residual Current Device 6kA 40A | 30mA C Curve | Short Body by NHP

BRAND: NHP

SKU: DSRCB4030AI

$191.20 List price: $253.90

+ −

30 Days Return Delivery Options

Residual current device with 6kA short circuit capacity and 40A rated current—ideal for residential and commercial safety. Built for electrical protection, with 30mA leakage sensitivity and compact DIN rail design.

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Device Short Body w/ Overcurrent 6kA 40A 1Pole and N C Curve 30mA Type Ai

Brand: NHP

SKU: DSRCB4030AI

Alternatively Known As: RCD, RCBO, Earth Leakage Circuit Breaker

Technical Specifications

Rated Current: 40 A
Rated Voltage: 240 V
Rated Leakage Current: 30 mA
Frequency: 50/60 Hz
Rated Short Circuit Breaking Capacity: 6 kA
Voltage Type: AC
Trip Curve: C
Rated Impulse Withstand Voltage: 6 kV
Tripping Time: 40 ms
Min Service Voltage: 117 V
Max Operating Voltage: 255 V
Rated Residual Make Break Capacity: 6000 A
Protected Neutral Pole: Yes
Number of Poles Total: 2
Electrical Life: 10,000 cycles
Type of Electric Connection: Fork and pin
Isolator Application: Yes
Rated Insulation Voltage: 440 V
Concurrently Switching Neutral Conductor: Yes
Degree of Protection: IP20
Number of Protected Poles: 2
Mechanical Life: 20,000 cycles
Operating Temperature: -5 to 55 °C
Dimensions (H x L x W): 86mm x 68mm x 36mm
Weight: 0.25 kg

Key Features

6kA short circuit breaking capacity
40A rated current
30mA leakage current
C curve trip characteristic
DIN rail mounting

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, offices
Commercial: Retail, hospitality, workspaces
General: Any location requiring electrical safety devices

Standards & Compliance

Complies with AS/NZS 61009 for safety and performance standards.

Environmental Benefits

Energy-efficient design enhances electrical safety.

Warranty Information

2 years warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Device is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

DSRCB4030AI-AU-RCBO-6kA-1P-and-N-36mm-Datasheet.pdf (DSRCB4030AI-AU-RCBO-6kA-1P-and-N-36mm-Datasheet.pdf, 309 Kb) [Download]
