Residual Current Device RCCB 4 Pole | 100A 300mA | DIN Rail Mount by NHP
Residual current device RCCB with 4 pole design and switched neutral—ideal for residential and commercial electrical safety. Built for enhanced protection, with 100A current and 300mA leakage, and easy DIN rail installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Residual Current Device RCCB 3 Pole and Switched Neutral 100A 300mA Type A
Brand: NHP
SKU: DTRCD4100300A
Alternatively Known As: RCCB, Residual Current Circuit Breaker, RCD, Type A RCCB
Technical Specifications
- Number of Poles: 4
- Voltage Type: AC
- Frequency: 50/60 Hz
- Rated Current: 100 A
- Leakage Current Type: A
- Rated Leakage Current: 300 mA
- Min Service Voltage: 254 V
- Max Rated Operation Voltage: 456 V
- Rated Insulation Voltage: 500 V
- Rated Impulse Withstand Voltage: 4 kV
- Rated Fault Current: 10000 A
- Electrical Life: 10000 cycles
- Surge Current Capacity: 0.25 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section (Solid Core): 1-35 mm²
- Connectable Conductor Cross Section (Multi-Wired): 1-25 mm²
- Operating Temperature: 70 °C
- Ambient Temperature During Operating: -25-70 °C
- Storage Temperature: 70 °C
- Pollution Degree: 2
- Dimensions (H x L x W): 85mm x 75mm x 70mm
- Weight: 0.38 kg
Key Features
- 4 Pole design with switched neutral for enhanced safety.
- Rated current of 100A and leakage current of 300mA.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small commercial buildings
- Commercial: Retail and office spaces requiring electrical safety
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The NHP DIN-T Residual Current Device RCCB 3 Pole and Switched Neutral 100A 300mA Type A is available now for immediate purchase. Ideal for residential and commercial applications requiring enhanced electrical safety.
