Residual Current Relay Coil | 80 mm Opening Diameter | 170 A Rated Primary Current | Compatible with DPX³ Circuit Breakers | @Each of 1 | by Legrand
The Residual Current Relay Coil is designed for use with DPX³ circuit breakers, featuring an 80 mm opening diameter and a rated primary current of 170 A. Ideal for enhancing electrical safety in switchboards and power cabinets, this single-phase current converter ensures reliable residual current protection, making it essential for qualified electricians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Residual Current Relay Coil | 80 mm Opening Diameter | 170 A Rated Primary Current | Compatible with DPX³ Circuit Breakers | @Each of 1 | by Legrand
Brand: Legrand
SKU: 026093
Alternatively Known As: Residual Current Relay Coil, DPX Coil 80mm, Legrand DPX Coil
Technical Specifications
- Model: Single-phase current converter
- Rated primary current: 170 A
- Rated secondary current: 0.05 A
- Overcurrent limiting factor: FS 5
- Calibrated coil with contact protection
- Opening diameter: 80 mm
- Secondary connection: Screw connection
- Number of primary inputs: 1
- Snap mounting: No
- Dimensions (H x L x W): 80mm x 80mm x 80mm
- Weight: 0.3 kg
Key Features
- Residual current relay coil for adding residual current protection
- Compatible with DPX³ circuit breakers
- Single-phase current converter
- Rated primary current: 170 A
- Rated secondary current: 0.05 A
- Overcurrent limiting factor FS 5
- Calibrated coil with contact protection
- Opening diameter: 80 mm
- Secondary connection via screw connection
- One primary input
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards and proper integration with DPX³ circuit breakers.
Applications
- Use with DPX³ trip-free switches and DPX³ MCCBs equipped with residual current relay Cat.No 0 260 88
- Electrical switchboards and power cabinets requiring residual current protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of electrical faults and fire hazards
- Supports energy-efficient circuit protection systems
Warranty Information
Standard Legrand warranty applies, typically 1 year against manufacturing defects.
Available Now
Available for immediate purchase, ideal for electrical switchboards and power cabinets requiring residual current protection.
