Reversing Contactor 24VDC | 3-Pole Configuration | High Electrical Endurance | Compact Design | @Pack of 1 | by Clipsal
The Reversing Contactor 24VDC is designed for three-phase motor control, featuring a robust 3-pole configuration and a reliable 24V DC coil. Ideal for industrial automation and HVAC systems, this contactor ensures high electrical durability with up to 1 million operations. Its compact TeSys K design makes it perfect for control panels and machinery, providing efficient performance in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Reversing Contactor 24VDC | 3-Pole Configuration | High Electrical Endurance | Compact Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLP2K0901BD
Alternatively Known As: TeSys K Reversing Contactor, 24VDC Contactor, Schneider Electric LP2K0901BD, Motor Reversing Contactor, Industrial Contactor 24VDC
Technical Specifications
- Type: Reversing contactor
- Series: TeSys K
- Poles: 3P
- Utilization category: AC-3
- Rated operational voltage: up to 440V
- Rated operational current: 9A
- Auxiliary contacts: 1 NC
- Coil voltage: 24V DC
- Electrical durability: up to 1 million operations
- Mechanical durability: up to 30 million operations
- Mounting: DIN rail or screw
- Standards: IEC 60947-4-1, IEC 60947-5-1
- Dimensions (H x L x W): 58mm x 80mm x 45mm
- Weight: 0.25 kg
Key Features
- Reversing contactor for three-phase motors
- 3-pole configuration
- AC-3 utilization category up to 440V, 9A
- 1 normally closed (NC) auxiliary contact
- 24V DC coil for reliable operation
- Compact TeSys K series design
- High electrical and mechanical endurance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Motor control in industrial automation
- Reversing applications for three-phase motors
- Control panels for machinery
- HVAC systems
- Pumping stations
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy-efficient coil reduces power consumption
- Long operational life minimizes replacement waste
- RoHS compliant materials for reduced environmental impact
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal TeSys K Reversing Contactor SCHLP2K0901BD is available for immediate purchase. Ideal for industrial motor control and automation applications.
