Product Name/Title: Reversing Contactor | 9A AC-3 at 400V | Compact Design & Reliable Switching | by Clipsal
Brand: Clipsal
SKU: SCHLP5K0910BW3
Alternatively Known As: motor reversing contactor, forward reverse contactor, Clipsal reversing contactor, SCHLP5K0910BW3 contactor
Technical Specifications
- Rated operational current: 9A AC-3 at 400V
- Control voltage: 220-240V AC 50/60Hz
- Number of poles: 3
- Auxiliary contacts: 1 NO + 1 NC
- Utilization category: AC-3
- Mechanical durability: 10 million operations
- Electrical durability: 1.2 million operations
- Mounting: DIN rail or screw fixing
- Operating temperature: -5°C to +60°C
- Dimensions (H x L x W): 80mm x 90mm x 45mm
- Weight: 0.45 kg
Key Features
- Compact design for easy panel integration
- Reliable switching for forward and reverse motor operation
- High electrical and mechanical endurance
- DIN rail mounting for quick installation
- Low power consumption coil
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations.
Applications
- Industrial motor control
- Conveyor systems
- Pumps and fans
- Machinery requiring forward and reverse operation
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Energy-efficient coil reduces power consumption
- Durable construction extends product lifespan, reducing waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal SCHLP5K0910BW3 Reversing Contactor is available for immediate purchase. Ideal for industrial motor control applications requiring reliable forward and reverse operation.
