Reversing Valve | Compatible with R-410A | Safe Working Pressure 4200 kPa | Wide Operating Temperature Range | by Aspen Pumps
The Reversing Valve is designed for HVAC systems using R-410A refrigerant, offering a safe working pressure of up to 4,200 kPa and a wide operating temperature range from -30°C to 130°C. Certified by UL, VDE, and CQC, this valve ensures optimal performance and safety in both commercial and residential applications, making it an essential component for air conditioning and heat pump systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Reversing Valve | Compatible with R-410A | Safe Working Pressure 4200 kPa | Wide Operating Temperature Range | by Aspen Pumps
Brand: Aspen Pumps
SKU: 708-0812-20
Alternatively Known As: HVAC Reversing Valve, R-410A Reversing Valve, Heat Pump Reversing Valve
Technical Specifications
- Capacity: 21.2 kW (5.6 Tons)
- Connections: 1/2 inch and 3/4 inch
- Safe Working Pressure: 4,200 kPa
- Operating Temperature Range: -30°C to 130°C
- Certifications: UL, VDE, CQC
- Dimensions (H x L x W): 120mm x 150mm x 100mm
- Weight: 1.5 kg
Key Features
- Compatible with R-410A refrigerant
- Safe working pressure up to 4,200 kPa
- Wide operating temperature range from -30°C to 130°C
- Certified by UL, VDE, and CQC for safety and quality
Professional Installation Requirements
- Installation must be performed by a licensed HVAC technician to ensure compliance with safety standards and optimal system performance.
Applications
- HVAC systems using R-410A refrigerant
- Air conditioning and heat pump systems
- Commercial and residential refrigeration units
Standards & Compliance
- Complies with AS/NZS 60335 for electrical safety in appliances
- Complies with AS/NZS 5149 for refrigeration systems safety
Environmental Benefits
- Supports efficient HVAC system operation reducing energy consumption
- Compatible with environmentally safer refrigerants like R-410A
Warranty Information
Standard manufacturer warranty applies, typically 1 year against defects.
Available Now
The Aspen Pumps Reversing Valve is available for immediate purchase, ideal for HVAC and refrigeration system applications.
