RFID Safety Sensor STR1-SAFF03P8 | SIL 3 & Category 4 | IP67 & IP69K Rated | by SICK

BRAND: SICK
SKU: 1072713
$513.00 List price: $644.80
+ −
30 Days Return Delivery Options
The RFID Safety Sensor STR1-SAFF03P8 is designed for industrial safety systems, featuring a SIL 3 safety integrity level and two safe outputs. With an assured switch-on distance of 14 mm and an IP67/IP69K rated enclosure, it’s perfect for machine safety monitoring and automation applications, ensuring reliable performance in harsh environments.
Technical Specifications
  • Sensor principle: RFID
  • Number of safe outputs: 2
  • Auxiliary contact: 1 (switching behavior complementary to OSSDs)
  • Assured switch on distance Sao: 14 mm (-10 to +70 °C), 10 mm (-30 to -10 °C)
  • Assured switch off distance Sar: 28 mm
  • Active sensor surfaces: 3 (top, left and right sides)
  • Actuation directions: 5
  • Coding: Permanently coded
  • Safety integrity level: SIL 3 (IEC 61508)
  • Category: Category 4 (EN ISO 13849)
  • Performance level: PL e (EN ISO 13849)
  • PFHD: 5.21 x 10^-9
  • Mission time: 20 years
  • Type: Type 4 (EN ISO 14119)
  • Actuator coding level: High
  • Safe state on fault: At least one OSSD off
  • Connection type: 7-wire cable, 3 m length
  • Cable diameter: 5.5 mm, conductor cross section: 0.12 mm²
  • Cable material: PVC, conductor material: Copper
  • Protection class: III (IEC 61140)
  • Supply voltage: 24 V DC (19.2 - 28.8 V DC)
  • Power consumption: 50 mA
  • Output current: ≤ 100 mA
  • Response time: 40 ms
  • Release time: 100 ms
  • Risk time: 80 ms
  • Switch-on time: 2.5 s
  • Housing material: VISTAL®
  • Enclosure rating: IP67, IP69K
  • Operating temperature: -30 °C to +70 °C
  • Vibration resistance: 10 Hz to 55 Hz, 1 mm
  • Shock resistance: 30 g, 11 ms
  • EMC standards: EN IEC 61326-3-1, EN IEC 60947-5-2, EN IEC 60947-5-3, EN 300330 V2.1.1
  • Dimensions (H x L x W): 18mm x 26mm x 40mm
  • Weight: 0.185 kg
Key Features
  • RFID sensor principle with permanently coded actuator
  • Two safe outputs with one auxiliary contact
  • Assured switch on distance Sao of 14 mm (-10 to +70 °C)
  • Assured switch off distance Sar of 28 mm
  • High safety integrity level SIL 3 and Category 4 compliance
  • Self-monitoring semiconductor outputs (OSSDs)
  • IP67 and IP69K rated enclosure for harsh environments
  • LED status display and diagnostics indicator
  • Operating temperature range from -30 °C to +70 °C
Professional Installation Requirements
  • Installation should be performed by qualified personnel familiar with safety sensor systems and compliant with relevant safety standards.
Applications
  • Industrial safety systems requiring RFID sensor technology
  • Machine safety monitoring and control
  • Automation systems with safety output requirements
Standards & Compliance
  • AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
  • Durable housing and long mission time of 20 years reduce waste and replacement frequency
  • Low power consumption of 50 mA supports energy-efficient operation
Warranty Information

Warranty details available upon request from manufacturer; typically includes coverage against manufacturing defects.

Available Now

The SICK STR1-SAFF03P8 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and automation applications.
