RFID Safety Sensor STR1-SAFM03P5 | IP67 & IP69K Rated | SIL 3 Safety Level | by SICK
The RFID Safety Sensor STR1-SAFM03P5 is designed for industrial safety monitoring and machine guarding, featuring a robust IP67/IP69K rated housing and a safety integrity level of SIL 3. With a response time of just 40 ms and support for multiple actuation directions, this sensor ensures reliable performance in harsh environments, making it ideal for automated systems and access control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 24 V DC (19.2 V DC to 28.8 V DC)
- Power consumption: 50 mA
- Output current: ≤ 100 mA
- Response time: 40 ms
- Release time: 100 ms
- Risk time: 80 ms
- Switch-on time: 2.5 s
- Cable: 5-wire, 3 m length, PVC material, copper conductor
- Cable diameter: 5.5 mm, conductor cross section: 0.12 mm²
- Bend radius: > 8x cable diameter (fixed), > 12x cable diameter (moving)
- Dimensions (W x H x D): 40 mm x 18 mm x 26 mm
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.157 kg
Key Features
- RFID sensor principle with 2 safe outputs and 1 auxiliary contact
- Assured switch on distance Sao of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance Sar of 28 mm
- 3 active sensor surfaces (top, left and right sides)
- 5 actuation directions supported
- Universally coded actuator
- Safety integrity level SIL 3 (IEC 61508)
- Category 4 (EN ISO 13849) with Performance Level PL e
- Low coding level actuator coding (EN ISO 14119)
- Self-monitoring semiconductor outputs (OSSDs)
- Protection class III (IEC 61140) and Class 2 cULus classification
- LED display elements with diagnostics and status indicators
- Robust housing made of VISTAL® material
- IP67 and IP69K rated enclosure for harsh environments
- Operating temperature range from –30 °C to +70 °C
- Shock resistance 30 g, vibration resistance 10 Hz to 55 Hz
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure compliance with safety standards and proper integration into safety systems.
Applications
- Industrial safety monitoring
- Machine guarding
- Access control in automated systems
- Safety-related position detection
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable IP67/IP69K rated housing reduces need for frequent replacements
- Low power consumption (50 mA) contributes to energy efficiency
- Robust design minimizes waste through extended operational life
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK STR1-SAFM03P5 RFID Safety Sensor with Actuator is available for immediate purchase. Ideal for industrial safety and machine guarding applications.
