RFID Safety Sensor STR1-SAFM03P8 | SIL 3 Safety Level | IP67 & IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAFM03P8 is designed for industrial safety monitoring and control, featuring a SIL 3 safety integrity level and robust IP67/IP69K protection. With 2 safe outputs and 1 auxiliary contact, it ensures reliable operation in automation systems requiring high safety integrity. Ideal for machine guarding and access control, this sensor operates effectively in temperatures ranging from -30 °C to +70 °C.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- System part: Sensor with actuator
- Sensor principle: RFID
- Number of safe outputs: 2
- Auxiliary contact (AUX): 1 (Switching behavior complementary to OSSDs)
- Assured switch on distance Sao: 14 mm (–10 to +70 °C), 10 mm (–30 to –10 °C)
- Assured switch off distance Sar: 28 mm
- Active sensor surfaces: 3 (top, left, right)
- Actuation directions: 5
- Coding: Universally coded
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 5.21 x 10^-9
- Mission time: 20 years
- Type: Type 4 (EN ISO 14119)
- Actuator coding level: Low coding level
- Safe state in fault: At least one safety-related semiconductor output OFF
- Safe series connection: In control cabinet with diagnostics
- Connection type: Cable, 7-wire, 3 m length
- Long connecting cable: ≤ 200 m
- Cable diameter: 5.5 mm
- Conductor cross section: 0.12 mm²
- Bend radius fixed installation: > 8 x cable diameter
- Bend radius moving cable: > 12 x cable diameter
- Cable material: PVC
- Conductor material: Copper
- Display elements: LEDs with diagnostics and status display
- Protection class: III (IEC 61140)
- Classification cULus: Class 2
- Supply voltage: 24 V DC (19.2 to 28.8 V DC)
- Power consumption: 50 mA
- Output type: Self-monitoring semiconductor outputs (OSSDs)
- Output current: ≤ 100 mA
- Response time: 40 ms
- Release time: 100 ms
- Risk time: 80 ms
- Switch-on time: 2.5 s
- Housing material: VISTAL®
- Enclosure rating: IP67, IP69K
- Operating temperature: –30 °C to +70 °C
- Storage temperature: –30 °C to +70 °C
- Vibration resistance: 10 Hz to 55 Hz, 1 mm
- Shock resistance: 30 g, 11 ms
- EMC standards: EN IEC 61326-3-1, EN IEC 60947-5-2, EN IEC 60947-5-3, EN 300330 V2.1.1
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.185 kg
Key Features
- RFID sensor principle with 2 safe outputs and 1 auxiliary contact
- Assured switch on distance Sao of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance Sar of 28 mm
- 3 active sensor surfaces (top, left and right sides)
- 5 actuation directions with universal coding
- Safety integrity level SIL 3 (IEC 61508) and Category 4 (EN ISO 13849)
- Performance level PL e (EN ISO 13849) with mean probability of dangerous failure per hour 5.21 x 10^-9
- Safe state ensures at least one safety-related semiconductor output is OFF in fault condition
- Self-monitoring semiconductor outputs (OSSDs) with response time 40 ms
- Robust housing material VISTAL® with IP67 and IP69K protection ratings
- Operating temperature range –30 °C to +70 °C
- LED display elements with diagnostics and status indicators
Professional Installation Requirements
- Installation by qualified personnel is required to ensure compliance with safety standards and proper integration into control systems.
Applications
- Industrial safety monitoring and control
- Machine guarding and access control
- Automation systems requiring high safety integrity
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Low power consumption of 50 mA supports energy efficiency
- Robust IP67/IP69K rating ensures long service life in harsh environments
Warranty Information
Warranty details available upon request from manufacturer or distributor.
Available Now
The SICK STR1-SAFM03P8 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and automation applications requiring high safety integrity.
