RFID Safety Sensor STR1-SAXF03P8 | SIL 3 & Category 4 Compliance | IP67 & IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAXF03P8 is designed for industrial safety monitoring and machine guarding, featuring a robust design with SIL 3 and Category 4 compliance. With an assured switch-on distance of 14 mm and IP67/IP69K ratings, it ensures reliable performance in harsh environments, making it ideal for automation systems requiring high safety integrity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.17 kg
Key Features
- RFID sensor principle with permanently coded actuator
- Two safe outputs and one auxiliary contact with complementary switching behavior
- Assured switch on distance of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance of 28 mm
- Three active sensor surfaces (top, left and right sides)
- Five actuation directions
- High safety integrity level SIL 3 and Category 4 compliance
- Performance level PL e with mean probability of dangerous failure per hour (PFHD) of 5.21 x 10^-9
- Safe state maintained with at least one safety-related semiconductor output off in case of fault
- Safe series connection with diagnostics in control cabinet
- LED display elements with diagnostics and status indicators
- Protection class III and cULus Class 2 classification
- Operating voltage 24 V DC with 50 mA power consumption
- Response time 40 ms, release time 100 ms, risk time 80 ms, switch-on time 2.5 s
- Robust housing made of VISTAL® material
- IP67 and IP69K enclosure rating for harsh environments
- Wide ambient operating temperature range from –30 °C to +70 °C
- Vibration and shock resistant according to IEC standards
- Comprehensive certifications including EU, UK, ACMA, China-RoHS, TÜV, cULus
Professional Installation Requirements
- Installation by qualified personnel familiar with safety sensor systems and compliance with relevant safety standards is recommended.
Applications
- Industrial safety monitoring
- Machine guarding
- Access control in hazardous areas
- Automation systems requiring high safety integrity
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable and robust design reduces need for frequent replacements
- Low power consumption (50 mA) contributes to energy efficiency
- High reliability minimizes waste from failures and downtime
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK STR1-SAXF03P8 RFID Safety Sensor is available for immediate purchase. Ideal for industrial safety and automation applications requiring high integrity safety monitoring.
