RFID Safety Sensor STR1-SAXF0AC8 | SIL 3 Safety Integrity | IP67 & IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAXF0AC8 is designed for industrial safety monitoring and machine guarding, featuring a high safety integrity level SIL 3 and robust IP67/IP69K rated enclosure. With two safe outputs and a response time of 40 ms, it ensures reliable operation in hazardous areas, making it ideal for automation systems that require stringent safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.1 kg
Key Features
- RFID sensor principle with permanently coded actuator
- Two safe outputs and one auxiliary contact with complementary switching behavior
- Assured switch on distance of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance of 28 mm
- Three active sensor surfaces (top, left and right sides)
- Five actuation directions
- High safety integrity level SIL 3 and Category 4 with Performance Level PL e
- Safe state maintained with at least one safety-related semiconductor output off in fault conditions
- Safe series connection capability with T-connector and Flexi Loop
- LED display elements with diagnostics indicator and status display
- Protection class III and cULus Class 2 classification
- Operating voltage 24 V DC with 50 mA power consumption
- Response time 40 ms, release time 100 ms, risk time 80 ms
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure compliance with safety standards and proper sensor integration.
Applications
- Industrial safety monitoring
- Machine guarding
- Access control in hazardous areas
- Automation systems requiring high safety integrity
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Complies with AS/NZS 45001 – Occupational Health & Safety (aligned with ISO 45001)
Environmental Benefits
- Durable housing material VISTAL® ensures long product life reducing waste
- Low power consumption of 50 mA contributes to energy efficiency
- Robust IP67 and IP69K rated enclosure protects against dust and water ingress, reducing maintenance and replacement
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK STR1-SAXF0AC8 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and automation applications.
