RFID Safety Sensor STR1-SAXF10P8 | SIL 3 & Category 4 | IP67 & IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAXF10P8 is designed for industrial safety monitoring, featuring a SIL 3 safety integrity level and Category 4 compliance. With two safe outputs, an auxiliary contact, and a robust IP67/IP69K rated housing, this sensor ensures reliable machine guarding and automation system integration, making it ideal for environments requiring high safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor principle: RFID
- Number of safe outputs: 2
- Auxiliary contact: 1 (switching behavior complementary to OSSDs)
- Assured switch on distance Sao: 14 mm (–10 to +70 °C), 10 mm (–30 to –10 °C)
- Assured switch off distance Sar: 28 mm
- Active sensor surfaces: 3 (top, left, right)
- Actuation directions: 5
- Coding: Permanently coded
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 5.21 x 10^-9
- Mission time: 20 years
- Type: Type 4 (EN ISO 14119)
- Actuator coding level: High
- Safe state in fault: At least one OSSD off
- Connection type: Cable, 7-wire
- Cable length: 10 m
- Long connecting cable: ≤ 200 m
- Cable diameter: 5.5 mm
- Conductor cross section: 0.12 mm²
- Bend radius fixed installation: > 8 x cable diameter
- Bend radius moving cable: > 12 x cable diameter
- Cable material: PVC
- Conductor material: Copper
- Display elements: LEDs
- Diagnostics indicator: Yes
- Status display: Yes
- Protection class: III (IEC 61140)
- Classification cULus: Class 2
- Supply voltage: 24 V DC (19.2 to 28.8 V DC)
- Power consumption: 50 mA
- Output type: Self-monitoring semiconductor outputs (OSSDs)
- Output current: ≤ 100 mA
- Response time: 40 ms
- Release time: 100 ms
- Risk time: 80 ms
- Switch-on time: 2.5 s
- Dimensions (W x H x D): 40 mm x 18 mm x 26 mm
- Weight: 445 g
- Housing material: VISTAL®
- Enclosure rating: IP67, IP69K
- Ambient operating temperature: –30 °C to +70 °C
- Storage temperature: –30 °C to +70 °C
- Vibration resistance: 10 Hz to 55 Hz, 1 mm
- Shock resistance: 30 g, 11 ms
- EMC standards: EN IEC 61326-3-1, EN IEC 60947-5-2, EN IEC 60947-5-3, EN 300330 V2.1.1
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.445 kg
Key Features
- RFID sensor principle with permanently coded actuator
- Two safe outputs and one auxiliary contact with complementary switching behavior
- Assured switch on distance of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance of 28 mm
- Three active sensor surfaces (top, left and right sides)
- Five actuation directions
- High safety integrity level SIL 3 and Category 4 with Performance Level PL e
- Safe state maintained with at least one safety-related semiconductor output off in fault conditions
- Safe series connection possible in control cabinet with diagnostics
- LED display elements with diagnostics and status indicators
- Protection class III and cULus Class 2 classification
- Operating voltage 24 V DC with 50 mA power consumption
- Response time 40 ms, release time 100 ms, risk time 80 ms, switch-on time 2.5 s
- Robust housing material VISTAL® with IP67 and IP69K enclosure rating
- Wide ambient operating temperature range from –30 °C to +70 °C
- Vibration and shock resistant according to IEC standards
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure compliance with safety standards and proper integration into control systems.
Applications
- Industrial safety monitoring
- Machine guarding
- Automation systems requiring high safety integrity
- Control cabinets with diagnostic capabilities
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Complies with AS/NZS 45001 – Occupational Health & Safety (aligned with ISO 45001)
Environmental Benefits
- Durable housing and high reliability reduce waste and replacement frequency
- Low power consumption (50 mA) contributes to energy efficiency
- Compliant with China-RoHS and ECOLAB certificates ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK STR1-SAXF10P8 RFID Safety Sensor is available for immediate purchase. Ideal for industrial safety and automation applications requiring high integrity safety monitoring.
