RFID Safety Sensor STR1-SAXM03P8 | SIL 3 Safety Level | IP67 & IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAXM03P8 is designed for industrial safety monitoring and machine guarding, featuring a SIL 3 safety integrity level and robust IP67/IP69K enclosure ratings. With a reliable RFID sensor principle and multiple actuation directions, it ensures safe operation in hazardous environments, making it ideal for automation systems that require stringent safety measures.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.17 kg
Key Features
- RFID sensor principle with 2 safe outputs and 1 auxiliary contact
- Assured switch on distance Sao of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance Sar of 28 mm
- 3 active sensor surfaces (top, left and right sides)
- 5 actuation directions
- Universally coded
- Safety integrity level SIL 3 (IEC 61508)
- Category 4 (EN ISO 13849) with Performance Level PL e
- Safe state ensured by semiconductor outputs (OSSD) in fault conditions
- Safe series connection with diagnostics in control cabinet
- LED display elements with diagnostics and status indicators
- Protection class III (IEC 61140) and Class 2 cULus classification
- Supply voltage 24 V DC with 50 mA power consumption
- Self-monitoring semiconductor outputs with ≤ 100 mA output current
- Response time 40 ms, release time 100 ms, risk time 80 ms
- Housing made of durable VISTAL® material
- Enclosure rating IP67 and IP69K for harsh environments
- Operating temperature range –30 °C to +70 °C
- Vibration and shock resistant per IEC standards
- Comprehensive certifications including EU, UK, ACMA, China-RoHS, TÜV, cULus
Professional Installation Requirements
- Installation by qualified personnel trained in safety sensor systems is recommended to ensure compliance with safety standards and proper integration.
Applications
- Industrial safety monitoring
- Machine guarding
- Access control in hazardous areas
- Automation systems requiring RFID safety sensors
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Complies with AS/NZS 45001 – Occupational Health & Safety (aligned with ISO 45001)
Environmental Benefits
- Durable housing and high ingress protection reduce waste and replacement frequency
- Low power consumption (50 mA) supports energy efficiency
- Compliant with China-RoHS ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK STR1-SAXM03P8 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and automation applications requiring reliable RFID-based safety monitoring.
