RFID Safety Sensor STR1-SAXM10P5 | Two Safe Outputs | IP67 & IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAXM10P5 is designed for industrial safety monitoring and machine guarding, featuring two safe outputs and an auxiliary contact for enhanced safety. With a robust IP67 and IP69K enclosure rating, this sensor ensures reliable performance in harsh environments, making it ideal for automated systems and access control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor principle: RFID
- Number of safe outputs: 2
- Auxiliary contact: 1 (complementary switching behavior to OSSDs)
- Assured switch on distance Sao: 14 mm (–10 to +70 °C), 10 mm (–30 to –10 °C)
- Assured switch off distance Sar: 28 mm
- Active sensor surfaces: 3 (top, left, right)
- Actuation directions: 5
- Coding: Universally coded
- Safety integrity level: SIL 3 (IEC 61508)
- Category: 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 5.21 x 10^-9
- Mission time: 20 years
- Type: 4 (EN ISO 14119)
- Actuator coding level: Low coding level
- Safe state on fault: At least one safety-related semiconductor output OFF
- Connection type: Cable, 5-wire, 10 m length
- Cable diameter: 5.5 mm, conductor cross section: 0.12 mm²
- Bend radius fixed installation: > 8 x cable diameter
- Bend radius moving cable: > 12 x cable diameter
- Cable material: PVC, conductor material: Copper
- Display elements: LEDs with diagnostics and status display
- Protection class: III (IEC 61140)
- Supply voltage: 24 V DC (19.2 to 28.8 V DC)
- Power consumption: 50 mA
- Output current: ≤ 100 mA
- Response time: 40 ms
- Release time: 100 ms
- Risk time: 80 ms
- Switch-on time: 2.5 s
- Housing material: VISTAL®
- Enclosure rating: IP67, IP69K
- Operating temperature: –30 °C to +70 °C
- Storage temperature: –30 °C to +70 °C
- Vibration resistance: 10 Hz to 55 Hz, 1 mm
- Shock resistance: 30 g, 11 ms
- EMC standards: EN IEC 61326-3-1, EN IEC 60947-5-2, EN IEC 60947-5-3, EN 300330 V2.1.1
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.4 kg
Key Features
- RFID sensor principle with universal coding
- Two safe outputs and one auxiliary contact with complementary switching behavior
- Assured switch on distance Sao of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance Sar of 28 mm
- Three active sensor surfaces (top, left and right sides)
- Five actuation directions
- Safety integrity level SIL 3 (IEC 61508)
- Category 4 (EN ISO 13849) and Performance level PL e (EN ISO 13849)
- Low coding level actuator coding (EN ISO 14119)
- Safe state ensures at least one safety-related semiconductor output is OFF in fault condition
- Self-monitoring semiconductor outputs (OSSDs)
- Protection class III (IEC 61140) and Class 2 cULus classification
- LED display elements with diagnostics and status indicators
- Robust housing material VISTAL® with IP67 and IP69K enclosure rating
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with safety sensor wiring and compliance with relevant electrical and safety standards.
Applications
- Industrial safety monitoring
- Machine guarding
- Access control in automated systems
- Safety-related sensor applications
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Low power consumption of 50 mA supports energy efficiency
- Robust IP67 and IP69K rating ensures long service life in harsh environments
Warranty Information
Warranty details available upon request from SICK; typically includes coverage against manufacturing defects.
Available Now
The SICK STR1-SAXM10P5 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and machine guarding applications.
