RFID Safety Sensor STR1-SAXM10P8 | Two Safe Outputs | IP67 & IP69K Rated | SIL 3 Compliance | by SICK
The RFID Safety Sensor STR1-SAXM10P8 is designed for industrial safety monitoring, featuring two safe outputs and an auxiliary contact for enhanced safety. With a robust IP67 and IP69K rating, this sensor operates effectively in harsh environments, ensuring reliable performance in machine guarding and access control applications. Its long mission time of 20 years and low power consumption make it an eco-friendly choice for automation processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor principle: RFID
- Number of safe outputs: 2
- Auxiliary contact: 1 (complementary switching behavior to OSSDs)
- Assured switch on distance Sao: 14 mm (–10 to +70 °C), 10 mm (–30 to –10 °C)
- Assured switch off distance Sar: 28 mm
- Active sensor surfaces: 3 (top, left, right)
- Actuation directions: 5
- Coding: Universally coded
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 5.21 x 10^-9
- Mission time: 20 years
- Type: Type 4 (EN ISO 14119)
- Actuator coding level: Low
- Safe state on fault: At least one safety-related semiconductor output OFF
- Connection type: Cable, 7-wire, 10 m length
- Cable diameter: 5.5 mm, conductor cross section: 0.12 mm²
- Cable material: PVC, conductor material: Copper
- Protection class: III (IEC 61140)
- Supply voltage: 24 V DC (19.2 to 28.8 V DC)
- Power consumption: 50 mA
- Output type: Self-monitoring semiconductor outputs (OSSDs)
- Output current: ≤ 100 mA
- Response time: 40 ms
- Release time: 100 ms
- Risk time: 80 ms
- Switch-on time: 2.5 s
- Enclosure rating: IP67, IP69K
- Operating temperature: –30 °C to +70 °C
- Storage temperature: –30 °C to +70 °C
- Vibration resistance: 10 Hz to 55 Hz, 1 mm
- Shock resistance: 30 g, 11 ms
- EMC standards: EN IEC 61326-3-1, EN IEC 60947-5-2, EN IEC 60947-5-3, EN 300330 V2.1.1
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.445 kg
Key Features
- RFID sensor principle with universal coding
- Two safe outputs and one auxiliary contact with complementary switching behavior
- Assured switch on distance of 14 mm (–10 to +70 °C) and 10 mm (–30 to –10 °C)
- Assured switch off distance of 28 mm
- Three active sensor surfaces (top, left and right sides)
- Five actuation directions
- Safety integrity level SIL 3 and Category 4 compliance
- Performance level PL e with low coding actuator level
- Self-monitoring semiconductor outputs (OSSDs)
- Protection class III and IP67, IP69K enclosure rating
- Operating temperature range from –30 °C to +70 °C
- LED display elements with diagnostics and status indicators
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with safety sensor integration and electrical wiring standards to ensure compliance and optimal performance.
Applications
- Industrial safety monitoring
- Machine guarding
- Access control in automated systems
- Safety-related automation processes
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable housing and long mission time of 20 years reduce waste and replacement frequency
- Low power consumption of 50 mA supports energy efficiency
Warranty Information
Warranty details available upon request from manufacturer; typically includes coverage against manufacturing defects.
Available Now
The SICK STR1-SAXM10P8 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and automation applications.
