RFID Safety Sensor STR1-SAXU10P8 | SIL 3 Safety Level | IP67/IP69K Rated | by SICK
The RFID Safety Sensor STR1-SAXU10P8 is designed for industrial safety monitoring, featuring a SIL 3 safety integrity level and IP67/IP69K enclosure rating. With two safe outputs and a unique coding system, it ensures reliable operation in automation systems. Ideal for machine guarding and safety applications, this sensor offers robust performance in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor principle: RFID
- Number of safe outputs: 2
- Auxiliary contact: 1 (complementary switching behavior to OSSDs)
- Assured switch on distance Sao: 14 mm (-10 to +70 °C), 10 mm (-30 to -10 °C)
- Assured switch off distance Sar: 28 mm
- Active sensor surfaces: 3 (top, left, right sides)
- Actuation directions: 5
- Coding: Uniquely coded
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 5.21 x 10^-9
- Mission time: 20 years (EN ISO 13849)
- Type: Type 4 (EN ISO 14119)
- Actuator coding level: High coding level (EN ISO 14119)
- Safe state in fault: At least one safety-related semiconductor output (OSSD) OFF
- Connection type: Cable, 7-wire, 10 m length
- Cable diameter: 5.5 mm, conductor cross section 0.12 mm²
- Cable material: PVC, conductor material: Copper
- Protection class: III (IEC 61140)
- Classification cULus: Class 2
- Supply voltage: 24 V DC (19.2 - 28.8 V DC)
- Power consumption: 50 mA
- Output type: Self-monitoring semiconductor outputs (OSSDs)
- Output current: ≤ 100 mA
- Response time: 40 ms
- Release time: 100 ms
- Risk time: 80 ms
- Switch-on time: 2.5 s
- Housing material: VISTAL®
- Enclosure rating: IP67, IP69K
- Operating temperature: -30 °C to +70 °C
- Vibration resistance: 10 Hz to 55 Hz, 1 mm
- Shock resistance: 30 g, 11 ms
- EMC compliance: EN IEC 61326-3-1, EN IEC 60947-5-2, EN IEC 60947-5-3, EN 300330 V2.1.1
- Dimensions (H x L x W): 18mm x 26mm x 40mm
- Weight: 0.445 kg
Key Features
- RFID sensor principle with uniquely coded signals
- Two safe outputs and one auxiliary contact with complementary switching behavior
- Assured switch on distance Sao of 14 mm (-10 to +70 °C) and 10 mm (-30 to -10 °C)
- Assured switch off distance Sar of 28 mm
- Three active sensor surfaces (top, left, right sides) with five actuation directions
- High safety integrity level SIL 3 and Category 4 safety rating
- Performance level PL e with mean probability of dangerous failure per hour (PFHD) of 5.21 x 10^-9
- Safe state maintained by at least one safety-related semiconductor output (OSSD) in fault conditions
- Safe series connection capability with diagnostics in control cabinet
- LED display elements with diagnostics and status indicators
- Protection class III and Class 2 electrical classification
- Supply voltage 24 V DC with 50 mA power consumption
- Response time 40 ms, release time 100 ms, risk time 80 ms, switch-on time 2.5 s
- Robust housing made of VISTAL® material
- IP67 and IP69K rated enclosure for harsh environments
- Wide ambient operating temperature range from -30 °C to +70 °C
- Vibration and shock resistant according to IEC standards
- Comprehensive EMC compliance with multiple EN IEC standards
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with safety sensor systems and electrical wiring standards to ensure compliance and optimal safety performance.
Applications
- Industrial safety monitoring
- Machine guarding
- Automation systems requiring RFID safety sensors
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces waste and replacement frequency
- Low power consumption enhances energy efficiency
- Robust IP67/IP69K rating ensures long service life in harsh environments
Warranty Information
Warranty details available upon request from SICK; typically includes coverage against manufacturing defects.
Available Now
The SICK STR1-SAXU10P8 RFID Safety Sensor is available for immediate purchase, ideal for industrial safety and automation applications requiring reliable RFID safety monitoring.
