RG11 Quad-Shield Coax Cable 300m 75 Ohm LSZH Black Madison

BRAND: Madison
SKU: CC11QS300
$762.80 List price: $934.70
300 Meter ($2.54 per Meter)
+ −
30 Days Return Electricians Unlock Trade Access
Madison RG11 Quad-Shield coaxial cable, 300m, 75 Ohm. Ideal for free-to-air, satellite and CCTV installs.

Product Name/Title: Coaxial Cable Low Loss RG11 75Ω Quad Shielded | Enhanced Signal Protection | Black LSHF Sheath | by Madison

Brand: Madison

SKU: CC11QS300

Alternatively Known As: RG11 Quad Shield Coaxial Cable, Low Loss RG11 Cable, 75 Ohm Quad Shield Coax Cable

Technical Specifications
  • Applicable Standards: UL758
  • Number of Cores: 1
  • Conductor: 23 AWG BC (Bare Copper), 1/0.6 mm stranding
  • Conductor Area: 0.28 mm²
  • Conductor Diameter: 0.6 mm
  • Insulation Material: Solid PE
  • Insulation Thickness: 1.5 mm
  • Insulation Nominal OD: 3.7 mm
  • Braiding Thickness: 0.84 mm
  • Outer Sheath Material: LSHF (Low Smoke Halogen Free)
  • Outer Sheath Colour: Black
  • Outer Sheath Thickness: 1 mm
  • Outer Sheath Nominal OD: 6.2 mm
  • Max Conductor DC Resistance @ 20°C: 62.0 Ω/km
  • Nominal Characteristic Impedance @ 1 MHz: 75±3 Ω
  • Operating Temperature Range: -25°C to +90°C
  • Minimum Bend Radius (Installation): 62 mm
  • Approximate Mass: 5.5 kg per 100 m
  • Supply Pack Type: Wooden Reel
  • Dimensions (H x L x W): 22mm x 1000mm x 39mm
  • Weight: 5.5 kg
Key Features
  • Low loss RG11 coaxial cable
  • Quad shielded for enhanced signal protection
  • ROHS compliant
  • Black LSHF outer sheath for safety
  • Suitable for operating temperatures from -25°C to +90°C
  • Minimum bend radius of 62mm for installation
Professional Installation Requirements
  • Installation should be performed by qualified professionals to ensure proper handling and compliance with electrical standards.
Applications
  • Signal control systems
  • Communication systems
Standards & Compliance
  • Complies with AS/NZS 60035 – Electrical Equipment in Explosive Atmospheres
Environmental Benefits
  • ROHS compliant ensuring reduced hazardous substances
  • Low smoke halogen-free (LSHF) outer sheath reduces toxic emissions in case of fire
Warranty Information

Standard manufacturer warranty applies. Please refer to Madison for specific warranty details.

Available Now

The Madison Coaxial Cable Low Loss RG11 75Ω Quad 300 is available for immediate purchase, ideal for signal control and communication system applications.


FAQ

Q: What does the LSHF outer sheath offer on this cable?

A: It's a low smoke halogen-free sheath that reduces toxic emissions in case of fire, suiting signal control and communication systems.

Q: What impedance does this RG11 coaxial cable offer?

A: It has a 75Ω±3Ω nominal characteristic impedance at 1 MHz, suiting low loss signal transmission applications.


Terminate runs of this cable with a BNC male connector for RG6 where compatible coaxial connector types are needed.

Verify continuity on long RG11 runs with a coax cable tester before commissioning the installation.

For shorter cable runs, a low loss RG58 coaxial cable suits installations needing a 50Ω impedance instead.

Order with confidence — SCHNAP offers a 30-day return policy on electrical products.
