RG59 Coax Cable 500m 75 Ohm LSZH Madison

BRAND: Madison
SKU: CC59HF500
$5,607.50 List price: $6,871.30
3000 Meter ($1.87 per Meter)
+ −
30 Days Return Electricians Unlock Trade Access
Madison low loss RG59 coaxial cable, 500m, 75 Ohm, LSZH, 23 AWG BC conductor. Ideal for fire-rated comms and CCTV runs.

Product Name/Title: Coaxial Cable Low Loss RG59 75Ω LSZH | 23 AWG BC Conductor | Solid PE Insulation | by Madison

Brand: Madison

SKU: CC59HF500

Alternatively Known As: RG59 Coaxial Cable, Low Loss RG59 Cable, LSZH Coaxial Cable, 75 Ohm Coax Cable

Technical Specifications
  • Conductor: 1 core, 23 AWG BC (Bare Copper)
  • Insulation: Solid PE, 1.5mm thickness
  • Outer Sheath: LSZH, black color, 1mm thickness
  • Nominal Outer Diameter: 6.2mm
  • Max Conductor DC Resistance @ 20°C: 62.0Ω/km
  • Nominal Characteristic Impedance @ 1MHz: 75±3Ω
  • Operating Temperature Range: -25°C to +90°C
  • Minimum Bend Radius (Installation): 62mm
  • Approximate Mass: 5.5kg per 100m
  • Pack Type: Wooden Reel
  • Dimensions (H x L x W): 22mm x 3000mm x 39mm
  • Weight: 5.5 kg
Key Features
  • Low loss RG59 coaxial cable
  • LSZH (Low Smoke Zero Halogen) outer sheath for safety
  • Single core conductor with 23 AWG BC material
  • Solid PE insulation with 1.5mm nominal thickness
  • 75Ω characteristic impedance
  • Operating temperature range from -25°C to +90°C
  • RoHS compliant
Professional Installation Requirements
  • Installation should be performed by qualified professionals to ensure signal integrity and compliance with safety standards.
Applications
  • Signal control systems
  • Communication systems
Standards & Compliance
  • Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
  • LSZH outer sheath reduces toxic smoke and halogen emissions in case of fire
  • RoHS compliant, free from hazardous substances
Warranty Information

Standard manufacturer warranty applies.

Available Now

The Madison Coaxial Cable Low Loss RG59 75Ω LSZH 3000 is available for immediate purchase, ideal for signal control and communication system applications.


FAQ

Q: What is the benefit of the LSZH outer sheath on this cable?

A: The LSZH (Low Smoke Zero Halogen) outer sheath reduces toxic smoke and halogen emissions in case of fire, making it suited to safety-conscious installations.

Q: What operating temperature range does this cable support?

A: This Madison RG59 LSZH cable is rated for an operating temperature range of -25°C to +90°C, supporting use in a wide range of environments.


For standard PVC sheathed runs, the RG59 coaxial cable is also available in 100m, 300m, and 500m lengths.

Connections along the run can be finished using a coaxial cable stripping tool for clean, precise prep.

Termination on site is handled with a coax crimping tool sized for this connector range.

Available now from SCHNAP — trusted by Australian electricians and electrical contractors.
