RGB LED Proximity Sensor | 13 mm Sensing Distance | IP67 Rated | by SICK
The RGB LED Proximity Sensor is designed for precise object detection with a sensing distance of up to 13 mm and an RGB LED light source. Ideal for industrial automation, this sensor features multiple teach-in modes and an IP67 rated enclosure, ensuring reliable performance in challenging environments. With low power consumption and robust protection against short circuits, it’s perfect for applications requiring efficient and durable sensing solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensing distance: ≤ 13 mm with ±5 mm tolerance
- Light source: LED RGB (470 nm, 525 nm, 625 nm)
- Light spot size: 0.9 mm x 3.8 mm
- Output: Analog current 0-20 mA and digital PNP switching
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: < 100 mA
- Switching frequency: 50 kHz
- Response time: 10 µs
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Connection: Male M12, 4-pin connector
- Operating temperature: -20 °C to +60 °C
- Enclosure rating: IP67
- Dimensions (H x L x W): 53mm x 79mm x 30mm
- Weight: 0.1 kg
Key Features
- Sensing distance up to 13 mm with ±5 mm tolerance
- RGB LED light source with wavelengths 470 nm, 525 nm, 625 nm
- Light emission from the long side of housing with a 0.9 mm x 3.8 mm light spot
- Multiple teach-in modes including 1-point, 2-point, dynamic, and auto mode
- Adjustable delay time and light/dark switching output function
- Analog current output (0 mA to 20 mA) and digital PNP switching output
- Protection class III with reverse polarity and short-circuit protection
- Housing made of VISTAL® and optics made of COP
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -20 °C to +60 °C
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial automation for object detection
- Standard sensing applications requiring RGB LED indication
- Environments requiring IP67 rated sensors
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces replacement frequency and waste
- Low power consumption with efficient LED light source
- Complies with China-RoHS for hazardous substance reduction
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK KTX-WP9114124IZZZZ sensor is available for immediate purchase, ideal for industrial automation and sensing applications requiring reliable RGB LED indication.
