RGB LED Proximity Sensor | 13mm Sensing Distance | IP67 Rated | by SICK
The RGB LED Proximity Sensor is designed for precise object detection with a sensing distance of up to 13 mm and a robust IP67 enclosure. Ideal for industrial automation and manufacturing processes, this sensor features an analog voltage output and multiple teach-in modes, ensuring reliable performance in various applications. With a durable design and low power consumption, it’s perfect for quality assurance systems and robotics.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensing distance: ≤ 13 mm with ±5 mm tolerance
- Light source: LED RGB (470 nm, 525 nm, 625 nm)
- Light emission: Long side of housing with 0.9 mm x 3.8 mm spot size
- Output: 1 analog voltage output (0 V to 10 V), 1 digital PNP output
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: < 100 mA
- Switching frequency: 50 kHz
- Response time: 10 µs
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Housing material: VISTAL®
- Optics material: COP
- Connection: M12, 5-pin plug
- Enclosure rating: IP67
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Shock load: 30 g / 11 ms per IEC 60068-2-27
- Dimensions (H x L x W): 53mm x 79mm x 30mm
- Weight: 0.1 kg
Key Features
- Standard device type with large housing design
- LED light source with RGB wavelengths (470 nm, 525 nm, 625 nm)
- Sensing distance up to 13 mm with ±5 mm tolerance
- Multiple teach-in modes including 1-point, 2-point, dynamic, and auto
- Analog voltage output (0 V to 10 V) and digital PNP output
- Adjustable delay time and light/dark switching output function
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water resistance
- Operating temperature range from -20 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection and positioning
- Manufacturing process control
- Quality assurance systems
- Robotics and material handling
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable IP67 housing reduces need for frequent replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK KTX-WP9114125UZZZZ sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
