RGB LED Proximity Sensor | IP67 Rated | 50 kHz Switching Frequency | 10 µs Response Time | by SICK
The RGB LED Proximity Sensor is designed for precise object detection in industrial automation, featuring a 50 kHz switching frequency and a rapid 10 µs response time. With an IP67 rating, it ensures durability in harsh environments, making it ideal for standard sensing applications. This sensor offers low power consumption and robust protection against reverse polarity and short circuits, ensuring reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: < 100 mA
- Switching frequency: 50 kHz
- Response time: 10 µs
- Light source: LED RGB with wavelengths 470 nm, 525 nm, 625 nm
- Light spot size: Ø 0.9 mm
- Switching output: Push-pull PNP/NPN, max 100 mA
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Connection type: Plug, M12, 5-pin
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Enclosure rating: IP67
- Shock resistance: 30 g/11 ms per IEC 60068-2-27
- Dimensions (H x L x W): 53mm x 79mm x 30mm
- Weight: 0.1 kg
Key Features
- Standard device type with large housing design
- LED RGB light source with wavelengths 470 nm, 525 nm, 625 nm
- Sensing distance up to 13 mm with ±3 mm tolerance
- Light/dark switching output function
- Adjustable delay time and multiple teach-in modes
- Push-pull PNP/NPN switching output with 100 mA max current
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water resistance
- Shock load resistance according to IEC 60068-2-27 (30 g/11 ms)
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation for object detection
- Standard sensing applications requiring precise detection
- Environments requiring robust IP67 rated sensors
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with less than 100 mA current draw
- Durable IP67 housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Warranty details available upon request from SICK; typically includes coverage against manufacturing defects.
Available Now
The SICK KTX-WB94141252ZZZZ sensor is available for immediate purchase, ideal for industrial automation and standard sensing applications.
