RGB LED Proximity Sensor | IP67 Rated | 50 kHz Switching Frequency | NPN Output | by SICK
The RGB LED Proximity Sensor is designed for industrial automation, featuring a robust IP67 rated enclosure and a high switching frequency of 50 kHz. With a sensing distance of up to 13 mm and multiple teach-in modes, it’s perfect for applications requiring reliable object detection and RGB LED indication. Built for durability and low power consumption, this sensor is ideal for environments where precision and efficiency are paramount.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: < 100 mA
- Switching frequency: 50 kHz
- Response time: 10 µs
- Switching output: NPN, HIGH = VS, LOW ≤ 3 V
- Output current max: 100 mA
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Housing material: VISTAL®
- Optics material: COP
- Connection: Male M12, 4-pin connector
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Shock load: 30 g / 11 ms per IEC 60068-2-27
- Enclosure rating: IP67
- Dimensions (H x L x W): 53mm x 79mm x 30mm
- Weight: 0.1 kg
Key Features
- Standard device type with large housing design
- RGB LED light source with wavelengths 470 nm, 525 nm, 625 nm
- Sensing distance up to 13 mm with ±5 mm tolerance
- Light emission from the long side of housing with a 0.9 mm x 3.8 mm light spot
- Multiple teach-in modes including 1-point, 2-point, dynamic, and auto
- Adjustable delay time and light/dark switching output function
- NPN switching output with max output current of 100 mA
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water resistance
- Operating temperature range from -20 °C to +60 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and sensor alignment.
Applications
- Industrial automation for object detection
- Standard sensing applications requiring RGB LED indication
- Environments requiring IP67 rated sensors
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with less than 100 mA current draw
- Durable IP67 housing reduces need for frequent replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK KTX-WN91141242ZZZZ sensor is available for immediate purchase, ideal for industrial automation and standard sensing applications requiring reliable RGB LED indication.
