RGB LED Sensor | IP67 Rated | NPN Output | 50 kHz Switching Frequency | by SICK
The RGB LED Sensor is designed for industrial automation, featuring an IP67 rated enclosure for dust and water resistance. With a switching frequency of 50 kHz and NPN output, it ensures reliable object detection and position sensing in various applications, including quality control and material handling. Built for efficiency, it operates within a wide temperature range and offers low power consumption.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: < 100 mA
- Switching frequency: 50 kHz
- Response time: 10 µs
- Light source: LED RGB with wavelengths 470 nm, 525 nm, 625 nm
- Light emission: Long side of housing
- Light spot size: 3.8 mm x 0.9 mm
- Switching output: NPN, HIGH = VS, LOW ≤ 3 V
- Output current max: 100 mA
- Connection type: Plug, M12, 5-pin
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Enclosure rating: IP67
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Shock load: 30 g / 11 ms per IEC 60068-2-27
- Dimensions (H x L x W): 53mm x 79mm x 30mm
- Weight: 0.1 kg
Key Features
- Standard device type with large housing design
- LED RGB light source with wavelengths 470 nm, 525 nm, 625 nm
- Sensing distance up to 13 mm with ±5 mm tolerance
- Light/dark switching output function with adjustable delay time
- 1-point and 2-point teach-in modes, dynamic teach-in, and auto mode
- NPN switching output with max output current of 100 mA
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water resistance
- Operating temperature range from -20 °C to +60 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and configuration of the sensor.
Applications
- Industrial automation for object detection
- Quality control in manufacturing
- Position sensing in robotics
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption with less than 100 mA current draw
- Durable IP67 housing reduces need for frequent replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK KTX-WN92141252ZZZZ RGB LED Sensor is available for immediate purchase, ideal for industrial automation and sensing applications.
