Ring Bolt DIN 580 | M6 Metric Thread | Zinc-Plated Steel | 75 kg Load Capacity | @Pack of 5 | by Wurth
The Ring Bolt DIN 580 is designed for lifting and securing loads, featuring a durable M6 metric thread and a maximum load capacity of 75 kg. Made from case hardening steel with a zinc-plated surface, it offers excellent corrosion resistance, making it ideal for industrial and construction applications. Perfect for hoisting equipment and general-purpose fastening, this reliable lifting eye bolt ensures safety and compliance in every use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Bolt DIN 580 | M6 Metric Thread | Zinc-Plated Steel | 75 kg Load Capacity | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 29596
Alternatively Known As: Lifting Eye Bolt, Eye Bolt M6, DIN 580 Eye Bolt, Zinc Plated Ring Bolt
Technical Specifications
- Thread type x nominal diameter (d1): M6
- Diameter of contact surface (d2): 20 mm
- Outer diameter (d3): 36 mm
- Internal diameter (d4): 20 mm
- Height (h1): 36 mm
- Length (l1): 13 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated, blue passivated (A2K)
- RoHS-compliant: Yes
- Max. load capacity: 75 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 1 mm
- Thread form: Standard metric thread
- Thread length (metric thread): 11.5 mm
- EC declaration of conformity (CE): Yes
- Dimensions (H x L x W): 36mm x 13mm x 36mm
- Weight: 0.05 kg
Key Features
- Made from case hardening steel C15E (1.1141) for durability
- Zinc-plated and blue passivated surface for corrosion resistance
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Complies with DIN 580 standard
- Metric thread M6 with 1 mm pitch and 11.5 mm thread length
- Maximum load capacity of 75 kg
- Includes lifting eye head type
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Lifting and securing loads in industrial and construction settings
- Attachment points for hoisting equipment
- General purpose fastening requiring lifting eye bolts
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Ring Bolt DIN 580 M6 zinc-plated steel is available for immediate purchase, ideal for industrial lifting and securing applications.
