Ring Bolt DIN 580 | Zinc-Plated Steel | 1200 kg Load Capacity | M20 Metric Thread | @Pack of 5 | by Wurth
The Ring Bolt DIN 580 is a robust lifting eye bolt made from case hardening steel, featuring a zinc-plated surface for enhanced corrosion resistance. With a maximum load capacity of 1200 kg and a standard M20 metric thread, it's perfect for industrial lifting and rigging applications. Designed for safety and compliance, this bolt is ideal for construction and structural fastening needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Bolt DIN 580 | Zinc-Plated Steel | 1200 kg Load Capacity | M20 Metric Thread | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 295920
Alternatively Known As: Lifting eye bolt, DIN 580 eye bolt, Zinc plated ring bolt, Load ring bolt
Technical Specifications
- Thread type x nominal diameter: M20
- Diameter of contact surface: 40 mm
- Outer diameter: 72 mm
- Internal diameter: 40 mm
- Height: 71 mm
- Length: 30 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated, blue passivated (A2K)
- Max. load capacity: 1200 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 2.5 mm
- Thread form: Standard metric thread
- Thread length: 25 mm
- EC declaration of conformity (CE): Yes
- RoHS-compliant: Yes
- Dimensions (H x L x W): 71mm x 30mm x 72mm
- Weight: 0.3 kg
Key Features
- Made from case hardening steel (C15E) for high strength
- Zinc-plated and blue passivated (A2K) surface for corrosion resistance
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Complies with DIN 580 standard
- Maximum load capacity of 1200 kg
- Metric thread with standard pitch of 2.5 mm
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Lifting and rigging applications
- Industrial machinery and equipment
- Construction and structural fastening
- General purpose load securing
Standards & Compliance
- Complies with AS/NZS 1252 for lifting and rigging hardware
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Standard manufacturer warranty against defects in materials and workmanship.
Available Now
Wurth Ring Bolt DIN 580 zinc-plated steel M20 is available for immediate purchase, ideal for industrial lifting and rigging applications.
