Ring Bolt DIN 580 | Zinc-Plated Steel | 1800 kg Load Capacity | Blue Passivated | @Pack of 5 | by Wurth
The Ring Bolt DIN 580 is crafted from durable zinc-plated steel, offering an impressive 1800 kg load capacity, making it ideal for industrial lifting and construction applications. With its blue passivated finish, this lifting eye bolt ensures corrosion resistance and longevity, perfect for securing heavy loads safely and efficiently.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Bolt DIN 580 | Zinc-Plated Steel | 1800 kg Load Capacity | Blue Passivated | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 295924
Alternatively Known As: Lifting eye bolt, DIN 580 eye bolt, ring fastener, lifting ring bolt
Technical Specifications
- Thread type x nominal diameter (d1): M24
- Diameter of contact surface (d2): 50 mm
- Outer diameter (d3): 90 mm
- Internal diameter (d4): 50 mm
- Height (h1): 90 mm
- Length (l1): 36 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated with blue passivation (A2K)
- Max. load capacity: 1800 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 3 mm
- Thread form: Standard metric thread
- Thread length (metric thread): 30 mm
- EC declaration of conformity (CE): Yes
- Dimensions (H x L x W): 90mm x 36mm x 90mm
- Weight: 0.5 kg
Key Features
- Made from case hardening steel, 1.1141, C15E for durability
- Zinc plated with blue passivation (A2K) for corrosion resistance
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Complies with DIN 580 standard
- Max load capacity of 1800 kg
- Metric thread with standard pitch of 3 mm
Professional Installation Requirements
- Installation should be performed by qualified personnel following the provided instructions to ensure safety and compliance.
Applications
- Industrial lifting and rigging
- Construction and machinery assembly
- Material handling and securing loads
Standards & Compliance
- Complies with AS/NZS 1252 – High tensile fasteners
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Ring Bolt DIN 580 M24 zinc-plated steel is available for immediate purchase, ideal for industrial lifting and construction applications.
