Ring Bolt DIN 580 | Zinc-Plated Steel | 3200 kg Load Capacity | Corrosion Resistant | @Each of 1 | by Wurth
The Ring Bolt DIN 580 is a robust lifting eye bolt made from case hardening steel, featuring a maximum load capacity of 3200 kg. With its zinc plating and blue passivation, it offers excellent corrosion resistance, making it ideal for industrial lifting and rigging applications. Perfect for construction, machinery, and marine use, this bolt ensures safety and compliance with AS/NZS 1252 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Bolt DIN 580 | Zinc-Plated Steel | 3200 kg Load Capacity | Corrosion Resistant | @Each of 1 | by Wurth
Brand: Wurth
SKU: 295930
Alternatively Known As: Lifting Eye Bolt, Eye Bolt DIN 580, Zinc Plated Ring Bolt, Lifting Ring Bolt
Technical Specifications
- Thread type x nominal diameter (d1): M30
- Diameter of contact surface (d2): 65 mm
- Outer diameter (d3): 108 mm
- Internal diameter (d4): 60 mm
- Height (h1): 109 mm
- Length (l1): 45 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated with blue passivation (A2K)
- RoHS-compliant: Yes
- Max. load capacity: 3200 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 3.5 mm
- Thread form: Standard metric thread
- Thread length (metric thread): 38 mm
- EC declaration of conformity (CE): Yes
- Dimensions (H x L x W): 109mm x 45mm x 108mm
- Weight: 1.5 kg
Key Features
- Made from case hardening steel, 1.1141, C15E for high strength
- Zinc plated with blue passivation (A2K) for corrosion resistance
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Complies with DIN 580 standard
- Maximum load capacity of 3200 kg
- Metric thread with standard pitch of 3.5 mm
Professional Installation Requirements
- Installation should be performed by qualified personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Lifting and rigging applications
- Industrial machinery and equipment
- Construction and structural fastening
- Marine and transport securing
Standards & Compliance
- Complies with AS/NZS 1252 for lifting and rigging hardware
Environmental Benefits
- RoHS-compliant material ensures reduced hazardous substances
- Durable zinc plating extends product life reducing replacement frequency
Warranty Information
Warranty against manufacturing defects as per Wurth standard policy.
Available Now
The Wurth Ring Bolt DIN 580 zinc-plated steel M30 is available for immediate purchase, ideal for industrial lifting and rigging applications.
