Ring Nut DIN 582 | A4 Stainless Steel | 140 kg Load Capacity | M8 | @Pack of 5 | by Wurth
The Ring Nut DIN 582 is crafted from durable A4 stainless steel, offering a robust 140 kg load capacity, making it ideal for secure fastening in lifting and rigging applications. Perfect for industrial and construction tasks, this nut features a plain surface finish and is RoHS-compliant, ensuring safety and reliability in mechanical assemblies.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Nut DIN 582 | A4 Stainless Steel | 140 kg Load Capacity | M8 | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 3898
Alternatively Known As: DIN 582 Ring Nut, Stainless Steel Lifting Eye Nut, M8 Eye Bolt Nut
Technical Specifications
- Thread type x nominal diameter (d): M8
- Internal diameter (d1): 20 mm
- Outer diameter (d2): 36 mm
- Diameter of contact surface (d3): 20 mm
- Material: Stainless steel A4
- Surface: Plain
- Load capacity (F max): 140 kg
- Nominal diameter: 8 mm
- RoHS-compliant: Yes
- Dimensions (H x L x W): 8mm x 36mm x 36mm
- Weight: 0.05 kg
Key Features
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Made from durable stainless steel A4 for corrosion resistance
- Plain surface finish
- RoHS-compliant
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided instructions to ensure safety and compliance.
Applications
- Used for secure fastening in lifting and rigging applications
- Suitable for industrial, construction, and mechanical assembly tasks
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Made from stainless steel which is recyclable and corrosion resistant, reducing replacement frequency
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Ring Nut DIN 582 A4 Stainless Steel M8 - 5 PCS is available for immediate purchase, ideal for industrial and construction fastening applications.
