Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | 3200 kg Load Capacity | @PCS of 1 | by Wurth
The Ring Nut DIN 582 is crafted from high-strength Steel C15E, featuring a zinc-plated and blue passivated finish for enhanced corrosion resistance. With a robust load capacity of 3200 kg, it's perfect for industrial lifting, construction, and machinery assembly. Designed for safety and compliance, this ring nut is ideal for professionals seeking reliable fastening solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | 3200 kg Load Capacity | @PCS of 1 | by Wurth
Brand: Wurth
SKU: 395930
Alternatively Known As: Lifting ring nut, DIN 582 ring bolt, steel lifting eye bolt, zinc plated ring fastener
Technical Specifications
- Thread type x nominal diameter (d): M30
- Internal diameter (d1): 60 mm
- Outer diameter (d2): 108 mm
- Diameter of contact surface (d3): 65 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated with blue passivation
- Load capacity (F max): 3200 kg
- RoHS-compliant: Yes
- Dimensions (H x L x W): 60mm x 108mm x 108mm
- Weight: 0.5 kg
Key Features
- Ring fasteners stamped with W.L.L. and manufacturer markings as per AS requirements
- Made from case hardening steel (1.1141, C15E) for high strength
- Zinc plated with blue passivation for corrosion resistance
- Load capacity up to 3200 kg
Professional Installation Requirements
- Installation should be performed by qualified personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Industrial lifting and rigging
- Construction and machinery assembly
- Load securing and fastening
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth warranty policy for details.
Available Now
The Wurth Ring Nut DIN 582 Steel C15E Zinc-Plated Blue Passivated M30 is available for immediate purchase, ideal for industrial lifting and construction applications.
