Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | 700 kg Load Capacity | @Pack of 5 | by Wurth
The Ring Nut DIN 582 is crafted from high-strength Steel C15E, featuring a zinc-plated and blue passivated finish for enhanced corrosion resistance. With a load capacity of 700 kg, it's perfect for industrial lifting, rigging, and construction applications. Designed for secure fastening, this nut ensures safety and compliance in all your machinery assembly and maintenance tasks.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | 700 kg Load Capacity | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 395916
Alternatively Known As: DIN 582 Ring Nut, Lifting Eye Nut, Steel Ring Fastener, Zinc Plated Ring Nut
Technical Specifications
- Thread type x nominal diameter (d): M16
- Internal diameter (d1): 35 mm
- Outer diameter (d2): 63 mm
- Diameter of contact surface (d3): 35 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated with blue passivation
- Load capacity (F max): 700 kg
- RoHS-compliant: Yes
- Dimensions (H x L x W): 35mm x 63mm x 63mm
- Weight: 0.15 kg
Key Features
- Ring fasteners stamped with W.L.L. and manufacturer markings as per AS requirements
- Made from case hardening steel, 1.1141, C15E for high strength
- Zinc plated with blue passivation for corrosion resistance
- Load capacity of 700 kg
- RoHS-compliant
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Industrial lifting and rigging
- Machinery assembly and maintenance
- Construction and structural applications
- General fastening and securing tasks
Standards & Compliance
- Complies with AS/NZS 1252 for lifting and rigging hardware
Environmental Benefits
- RoHS-compliant ensuring reduced hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Standard manufacturer warranty against defects in materials and workmanship.
Available Now
Wurth Ring Nut DIN 582 Steel C15E Zinc-Plated Blue Passivated M16 5 PCS is available for immediate purchase, ideal for industrial and construction applications requiring secure lifting points.
