Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | Load Capacity 1200 kg | @Pack of 5 | by Wurth
The Ring Nut DIN 582 is crafted from high-strength Steel C15E, featuring a zinc-plated and blue passivated finish for enhanced corrosion resistance. With a load capacity of 1200 kg, it's perfect for industrial lifting and rigging applications. Designed for mechanical fastening and securing, this nut ensures safety and compliance when installed by qualified personnel.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | Load Capacity 1200 kg | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 395920
Alternatively Known As: DIN 582 Ring Nut, Lifting Eye Nut, Steel Ring Fastener, Zinc Plated Eye Bolt Nut
Technical Specifications
- Thread type x nominal diameter (d): M20
- Internal diameter (d1): 40 mm
- Outer diameter (d2): 72 mm
- Diameter of contact surface (d3): 40 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated with blue passivation
- Load capacity (F max): 1200 kg
- Nominal diameter: 20 mm
- RoHS-compliant: Yes
- Dimensions (H x L x W): 40mm x 40mm x 72mm
- Weight: 0.15 kg
Key Features
- Ring fasteners stamped with W.L.L. and manufacturer markings as per AS requirements
- Made from case hardening steel (C15E) for high strength
- Zinc plated with blue passivation for corrosion resistance
- Load capacity of 1200 kg
- RoHS-compliant
Professional Installation Requirements
- Installation should be performed by qualified personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Industrial lifting and rigging
- Mechanical fastening and securing
- Construction and maintenance
- Machinery assembly and repair
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- RoHS-compliant ensuring reduced hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Standard manufacturer warranty against defects applies. Refer to Wurth warranty policy.
Available Now
Wurth Ring Nut DIN 582 Steel C15E Zinc-Plated Blue Passivated M20 5 PCS is available for immediate purchase, ideal for industrial and construction lifting applications.
