Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | Load Capacity 140 kg | @Pack of 5 | by Wurth
The Ring Nut DIN 582 is crafted from durable Steel C15E and features a zinc-plated, blue passivated finish, ensuring corrosion resistance. With a load capacity of 140 kg, it's perfect for lifting and securing loads in industrial and construction settings. Ideal for machinery and structural fastening, this nut is RoHS-compliant, making it a reliable choice for maintenance and repair operations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Nut DIN 582 | Steel C15E | Zinc-Plated & Blue Passivated | Load Capacity 140 kg | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 39598
Alternatively Known As: Lifting Ring Nut, Eye Nut, Load Ring, DIN 582 Ring Bolt
Technical Specifications
- Thread type x nominal diameter (d): M8
- Internal diameter (d1): 20 mm
- Outer diameter (d2): 36 mm
- Diameter of contact surface (d3): 20 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Zinc plated with blue passivation
- Load capacity (F max): 140 kg
- RoHS-compliant: Yes
- Dimensions (H x L x W): 20mm x 20mm x 36mm
- Weight: 0.05 kg
Key Features
- Ring fasteners stamped with W.L.L. and manufacturer markings as per AS requirements
- Made from case hardening steel (1.1141, C15E) for durability
- Zinc plated with blue passivation for corrosion resistance
- Load capacity of 140 kg
- RoHS-compliant ensuring environmental safety
Professional Installation Requirements
- Installation should follow the provided instructions and be performed by qualified personnel to ensure safety and compliance.
Applications
- Used for lifting and securing loads in industrial and construction settings
- Suitable for machinery, equipment, and structural fastening
- Ideal for use in maintenance and repair operations requiring reliable load-bearing fasteners
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Zinc plating extends product life reducing waste and replacement frequency
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Ring Nut DIN 582 Steel C15E Zinc-Plated Blue Passivated M8 5 PCS is available for immediate purchase, ideal for industrial lifting and securing applications.
