Ring Screw DIN 580 | Case Hardening Steel C15E | 230 kg Load Capacity | Plain Finish | @Pack of 5 | by Wurth
The Ring Screw DIN 580 is crafted from durable case hardening steel C15E, offering a robust 230 kg load capacity. Ideal for industrial lifting and rigging applications, this screw features a plain surface finish and complies with DIN 580 standards. Perfect for construction and machinery assembly, it ensures safety and reliability in load securing and material handling tasks.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Screw DIN 580 | Case Hardening Steel C15E | 230 kg Load Capacity | Plain Finish | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 2959010
Alternatively Known As: Lifting eye bolt, DIN 580 eye screw, steel lifting ring, rigging screw, lifting ring bolt
Technical Specifications
- Thread type x nominal diameter: M10
- Diameter of contact surface: 25 mm
- Outer diameter: 45 mm
- Internal diameter: 25 mm
- Height: 45 mm
- Length: 17 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Plain
- Max. load capacity: 230 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 1.5 mm
- Thread form: Standard metric thread
- Thread length: 14 mm
- EC declaration of conformity (CE): Yes
- Dimensions (H x L x W): 45mm x 17mm x 45mm
- Weight: 0.1 kg
Key Features
- Made from case hardening steel 1.1141, C15E for durability
- Plain surface finish
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Complies with DIN 580 standard
- Metric thread with pitch 1.5 mm
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Industrial lifting and rigging
- Construction and machinery assembly
- Load securing and material handling
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- RoHS-compliant material ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth warranty policy.
Available Now
Wurth Ring Screw DIN 580 Steel C15E Plain M10 5 PCS is available for immediate purchase, ideal for industrial lifting and rigging applications.
