Ring Screw DIN 580 | Case Hardening Steel C15E | 3200 kg Load Capacity | Plain Finish | @PCS by Wurth
The Ring Screw DIN 580 is crafted from case hardening steel C15E, offering a robust 3200 kg load capacity, making it ideal for lifting and rigging applications. Designed for industrial machinery and construction, this screw features a plain finish and complies with DIN 580 standards, ensuring safety and reliability in material handling tasks.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Screw DIN 580 | Case Hardening Steel C15E | 3200 kg Load Capacity | Plain Finish | @PCS by Wurth
Brand: Wurth
SKU: 2959030
Alternatively Known As: Lifting eye bolt, Ring bolt, Eye screw, DIN 580 eye bolt
Technical Specifications
- Thread type x nominal diameter (d1): M30
- Diameter of contact surface (d2): 65 mm
- Outer diameter (d3): 108 mm
- Internal diameter (d4): 60 mm
- Height (h1): 109 mm
- Length (l1): 45 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Plain
- RoHS-compliant: Yes
- Max. load capacity: 3200 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 3.5 mm
- Thread form: Standard metric thread
- Thread length (metric thread): 38 mm
- EC declaration of conformity (CE): Yes
- Dimensions (H x L x W): 109mm x 45mm x 108mm
- Weight: 1.5 kg
Key Features
- Made from case hardening steel 1.1141, C15E for high strength
- Complies with DIN 580 standard
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Plain surface finish
- Metric thread with standard pitch of 3.5 mm
- Max load capacity of 3200 kg
- Equipped with lifting eye for secure attachment
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Lifting and rigging applications
- Industrial machinery and equipment
- Construction and structural support
- Load securing and material handling
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- RoHS-compliant material ensuring reduced hazardous substances
- Durable steel construction promotes long product life and reduces waste
Warranty Information
Warranty against manufacturing defects as per Wurth standard policy.
Available Now
The Wurth Ring Screw DIN 580 Steel C15E Plain M30 is available for immediate purchase, ideal for industrial lifting and rigging applications.
