Ring Screw DIN 580 | Steel C15E | 700 kg Load Capacity | Plain Finish | @Pack of 5 | by Wurth
The Ring Screw DIN 580 is crafted from durable case hardening steel C15E, designed for lifting and rigging applications with a maximum load capacity of 700 kg. Ideal for securing loads in construction and industrial settings, this screw features a plain finish and a lifting eye for secure attachment, ensuring safety and compliance in all your lifting tasks.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ring Screw DIN 580 | Steel C15E | 700 kg Load Capacity | Plain Finish | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 2959016
Alternatively Known As: Lifting eye bolt, Ring bolt, DIN 580 eye screw, Steel lifting ring, Eye bolt M16
Technical Specifications
- Thread type x nominal diameter (d1): M16
- Diameter of contact surface (d2): 35 mm
- Outer diameter (d3): 63 mm
- Internal diameter (d4): 35 mm
- Height (h1): 62 mm
- Length (l1): 27 mm
- Material: Case hardening steel, 1.1141, C15E
- Surface: Plain
- RoHS-compliant: Yes
- Max. load capacity: 700 kg
- Head type: With lifting eye
- Thread type: Metric thread
- Pitch: 2 mm
- Thread form: Standard metric thread
- Thread length (metric thread): 23 mm
- EC declaration of conformity (CE): Yes
- Dimensions (H x L x W): 62mm x 27mm x 63mm
- Weight: 0.15 kg
Key Features
- Made from case hardening steel 1.1141, C15E for durability
- Stamped with W.L.L. and manufacturer markings as per AS requirements
- Complies with DIN 580 standard
- Plain surface finish
- Metric thread with standard pitch of 2 mm
- Max load capacity of 700 kg
- Includes lifting eye for secure attachment
Professional Installation Requirements
- Installation should be performed by trained personnel following the provided installation instructions to ensure safety and compliance.
Applications
- Lifting and rigging applications
- Securing loads in construction and industrial settings
- Attachment points for hoisting equipment
Standards & Compliance
- Complies with AS/NZS 1252 for lifting and rigging hardware
Environmental Benefits
- RoHS-compliant material ensuring reduced hazardous substances
- Durable steel construction promotes long product life and reduces waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth warranty terms.
Available Now
Wurth Ring Screw DIN 580 Steel C15E Plain M16 5 PCS is available for immediate purchase. Ideal for industrial lifting and securing applications.
