RSB1-0440B170130FZ3DZZZP0C | Photoelectric sensors
The SICK RSB1-0440B170130FZ3DZZZP0C is a durable photoelectric proximity sensor designed for precise object detection in industrial environments, featuring infrared LED technology and robust IP67 rated housing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RSB1-0440B170130FZ3DZZZP0C | Photoelectric sensors
Brand: SICK
SKU: 1153021
Alternatively Known As: Photoelectric proximity sensor, Infrared photo sensor, Industrial object sensor, SICK RSB1 sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 8 mA at 24 V DC without load
- Output type: PNP digital output, max 100 mA
- Response time: ≤ 1 ms
- Switching frequency: 500 Hz
- Protection class: III
- LED risk group: Free group
- Enclosure rating: IP67
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Shock resistance: 11 ms shocks per EN60068-2-27
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm per EN60068-2-6
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 17mm x 440mm x 20mm
- Weight: 0.16 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Sensing range from 2 mm to 300 mm, optimal 2 mm to 45 mm
- Infrared LED light source with 850 nm wavelength
- Point-shaped light spot size 27 mm x 29 mm at 45 mm distance
- Two beams with 170 mm separation and 130 mm distance from first beam to housing edge
- LED indicators for power and object detection status
- Robust metal aluminum anodised housing with PMMA front screen
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -40 °C to +60 °C
- High shock and vibration resistance
- Cable with M8 4-pin connector, 500 mm length
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and sensor alignment.
Applications
- Industrial automation for object detection
- Detecting flat, perforated, uneven, and shiny objects
- Position tolerance detection in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient LED light source minimizes power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK RSB1-0440B170130FZ3DZZZP0C photoelectric sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
