Safety Controller SmartPlug M5 | SIL 3 & PL e Certified | 36 Safety Inputs & 20 Outputs | IP65 to IP69K Enclosure | by SICK
The Safety Controller SmartPlug M5 is designed for industrial safety control systems, featuring 36 safety inputs and 20 safety outputs. With SIL 3 and PL e certification, it ensures reliable monitoring and switching of safety devices. Ideal for automation systems, this controller supports Ethernet Modbus TCP communication and is built to withstand harsh environments with an IP65 to IP69K enclosure rating.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Safety inputs: 36
- Safety outputs: 20
- Test outputs: 8
- Supply voltage: 24 V DC (16 V to 32 V)
- Protection class: III (IEC 61140)
- Communication: Ethernet Modbus TCP SLMP, USB SmartPlug
- Operating temperature: -25 °C to +60 °C
- Storage temperature: -40 °C to +85 °C
- Shock resistance: 100 g (6 ms), 30 g (11 ms)
- Contamination rating: 4 (IEC 61010-1)
- Mounting: 3 through-holes for M6 screws
- Dimensions (H x L x W): 57.6mm x 194mm x 266mm
- Weight: 1.95 kg
Key Features
- Safety integrity level SIL 3 (IEC 61508)
- Category 4 (ISO 13849-1) and Performance level PL e
- Monitoring, switching, and testing of connected safety devices
- Programmable logic with graphical function blocks
- Ethernet Modbus TCP SLMP communication interface
- IP65 to IP69K enclosure rating for harsh environments
- Supports up to 36 safety inputs and 20 safety outputs
- Includes USB SmartPlug for configuration and diagnostics
Professional Installation Requirements
- Installation and configuration should be performed by qualified professionals familiar with industrial safety systems and electrical standards.
Applications
- Industrial safety control systems
- Monitoring and switching of safety devices
- Automation systems requiring SIL 3 and PL e safety levels
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Enhances operational safety reducing risk of accidents and environmental hazards
- Durable IP65 to IP69K rated enclosure reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK FLM3-CPUN100A02 Safety Controller SmartPlug M5 is available for immediate purchase, ideal for industrial safety and automation applications.
