Safety Interlock Switch E100-B2A22S05A | IP65 Rated | 2 N/C & 2 N/O Contacts | Slow Action Switching | by SICK
The Safety Interlock Switch E100-B2A22S05A is designed for industrial safety systems, featuring 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts. With an IP65 rated enclosure, it ensures reliable operation in harsh environments, making it ideal for machinery safety interlocks and automation systems. Built for durability, it boasts a mechanical life of 100,000 switching cycles, minimizing downtime and enhancing safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Positive action N/C contacts: 2
- N/O contacts: 2
- Actuation directions: 1
- Switching principle: Slow action switching element
- Rated operating current: 2 A at 24 V DC, 100 mA at 24 V DC
- Rated insulation voltage Ui: 32 V
- Rated impulse withstand voltage Uimp: 800 V
- Short-circuit protection: 2 A gG / 0.1 A gG
- Switching voltage: ≥ 12 V DC
- Switching current: 1 mA at 24 V DC
- Cable length: 5 m
- Cable diameter: 9.8 mm
- Conductor cross section: 8 x 0.5 mm², 8 x 0.14 mm²
- Cable material: PUR
- Conductor material: Copper
- Enclosure rating: IP65 (EN 60529)
- Ambient operating temperature: –5 °C to +50 °C
- Mechanical life: 100,000 switching cycles
- Housing material: Plastic
- Dimensions (H x L x W): 132mm x 64mm x 64mm
- Weight: 1.32 kg
Key Features
- 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts
- Slow action switching element for reliable operation
- IP65 rated enclosure for protection against dust and water
- Plus/minus button for easy operation
- Cable open end connection with 5 m PUR cable and copper conductors
- Mechanical life of 100,000 switching cycles
Professional Installation Requirements
- Installation should be performed by a qualified professional familiar with safety switch wiring and safety-related control systems to ensure compliance and proper operation.
Applications
- Industrial safety systems requiring reliable safety switch monitoring
- Machinery safety interlocks
- Automation and control systems with safety requirements
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- High reliability minimizes downtime and resource consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK E100-B2A22S05A Safety Switch is available for immediate purchase, ideal for industrial safety and automation applications.
