Safety Laser Scanner L41E | 84m Scanning Range | Type 4 Safety Rated | IP67 Enclosure | by SICK
The Safety Laser Scanner L41E offers an impressive 84m scanning range and single beam detection with a 30mm capability, making it ideal for industrial safety monitoring and machine safeguarding. With a fast response time of 0.2 ms and a robust IP67 enclosure, this scanner ensures reliable performance in demanding environments, providing peace of mind for access protection and area monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Safety Laser Scanner L41E, SICK Laser Safety Sensor, Industrial Safety Scanner
Technical Specifications
- Scanning range: 84 m
- Number of beams: 1
- Detection capability: 30 mm
- Optical axis: Axial
- Response time: 0.2 ms + test device response time
- Safety type: Type 4 (IEC 61496-1)
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 8.1 x 10^-10 (EN ISO 13849)
- Mission time: 20 years (EN ISO 13849)
- Connection type: Male connector M12, 4-pin, angled
- Display elements: LED
- Protection class: III (IEC 61140)
- Power consumption: 30 mA
- Current-carrying capacity per OSSD: ≤ 70 mA
- Design: Cylindrical
- Housing material: Nickel-plated brass
- Front screen material: Glass
- Enclosure rating: IP67 (EN 60529)
- Operating temperature: -40 °C to +55 °C
- Storage temperature: -40 °C to +75 °C
- Air humidity: 15% to 95%, non-condensing
- Vibration resistance: 5 g, 10 Hz to 55 Hz (IEC 60068-2-6)
- Shock resistance: 10 g, 16 ms (IEC 60068-2-27)
- Aperture angle/receiving angle: ± 2.5° / ± 2.5°
- Dimensions (H x L x W): 30mm x 100mm x 30mm
- Weight: 0.212 kg
Key Features
- Scanning range of 84 m
- Single beam detection with 30 mm detection capability
- Axial optical axis
- Fast response time of 0.2 ms plus test device response time
- Type 4 safety rated according to IEC 61496-1
- Safety Integrity Level SIL 3 compliant (IEC 61508)
- Category 4 and Performance Level e (EN ISO 13849)
- High reliability with PFHD of 8.1 x 10^-10
- Long mission time of 20 years
- Male M12 4-pin angled connector
- LED display elements
- Protection class III (IEC 61140)
- Low power consumption of 30 mA
- Current carrying capacity per OSSD ≤ 70 mA
- Cylindrical design with nickel-plated brass housing and glass front screen
- IP67 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -40 °C to +55 °C
- Vibration and shock resistant
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with safety laser scanners and relevant safety standards to ensure compliance and optimal performance.
Applications
- Industrial safety monitoring
- Machine safeguarding
- Access protection
- Area monitoring in manufacturing environments
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption reduces energy usage
- Durable IP67 rated housing extends product life and reduces waste
- Long mission time of 20 years minimizes replacement frequency
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK L41E-33MA2A Safety Laser Scanner is available for immediate purchase, ideal for industrial safety and machine safeguarding applications.
