Safety Light Curtain Receiver M40E-66A303RB0 | Type 4 Compliance | 30 mm Resolution | 21 m Scanning Range | by SICK
The Safety Light Curtain Receiver M40E-66A303RB0 is designed for industrial safety applications, featuring a 30 mm resolution and a scanning range of up to 21 m. With Type 4 compliance and optical synchronization, it ensures reliable operation for machine safeguarding and access control. Built for durability, its robust aluminum housing and IP65 rating provide excellent protection against dust and water, making it ideal for automation and manufacturing safety systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Safety Light Curtain Receiver, Industrial Safety Sensor, M40E Receiver, SICK Safety Sensor
Technical Specifications
- System part: Receiver
- Resolution: 30 mm
- Scanning range: 21 m
- Protective field height: 1,200 mm
- Response time: 13 ms without beam coding, 21 ms with beam coding
- Synchronization: Optical synchronization
- Safety type: Type 4 (IEC 61496-1)
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 28 * 10^-9 (EN ISO 13849)
- Mission time: 20 years (EN ISO 13849)
- Safe state in fault: At least one OSSD is OFF
- System connection: Hirschmann male connector M26, 12-pin
- Permitted cable length: ≤ 50 m
- Extension connection: Female connector M12, 5-pin
- Configuration method: Via software
- Display elements: 7-segment display, LEDs
- Protection class: III (IEC 61140)
- Supply voltage: 24 V DC (19.2 V ... 28.8 V)
- Power consumption: ≤ 0.8 A
- Output signal switching devices: 2 PNP semiconductors, short-circuit protected
- Housing material: Aluminum alloy ALMGSI 0.5
- Surface treatment: Powder coated
- Front screen material: Polycarbonate, scratch-resistant coating
- Enclosure rating: IP65 (EN 60529)
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -30 °C to +70 °C
- Air humidity: 15% to 95%, non-condensing
- Vibration resistance: 5 g, 10 Hz to 55 Hz
- Shock resistance: 10 g, 16 ms
- Wavelength: 850 nm
- Dimensions (H x L x W): 55mm x 150mm x 52mm
- Weight: 1.5 kg
Key Features
- Type 4 safety light curtain receiver with IEC 61496-1 compliance
- Resolution of 30 mm and scanning range up to 21 m
- Protective field height of 1,200 mm
- Optical synchronization for reliable operation
- Response time: 13 ms without beam coding, 21 ms with beam coding
- Supports restart interlock, external device monitoring, beam coding, and configurable status output
- Safe SICK device communication via EFI
- Differentiation between man and material (muting) supported
- Robust aluminum alloy housing with powder coating and scratch-resistant polycarbonate front screen
- IP65 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -30 °C to +55 °C
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with safety light curtain systems and electrical safety standards to ensure compliance and optimal performance.
Applications
- Industrial safety light curtain applications
- Machine safeguarding and access control
- Automation and manufacturing safety systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Enhances workplace safety reducing accidents and environmental hazards
- Durable construction reduces waste and replacement frequency
- Energy-efficient operation minimizes power consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK M40E-66A303RB0 Safety Light Curtain Receiver is available for immediate purchase, ideal for industrial safety and automation applications.
