Safety Light Curtain Receiver M40E-66A323RB0 | 30 mm Resolution | 21 m Scanning Range | IP65 Rated | by SICK
The M40E-66A323RB0 Safety Light Curtain Receiver is designed for industrial safety applications, featuring a 30 mm resolution and a scanning range of up to 21 m. With a protective field height of 1,200 mm and a response time of 13 ms, it ensures reliable machine safeguarding and access protection. Built for durability, it operates in harsh environments with an IP65 rating, making it ideal for automation and manufacturing safety systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Safety light curtain receiver, M40E safety sensor, SICK light curtain, industrial safety sensor
Technical Specifications
- Resolution: 30 mm
- Scanning range: 21 m
- Protective field height: 1,200 mm
- Response time: 13 ms (without beam coding), 21 ms (with beam coding)
- Safety type: Type 4 (IEC 61496-1)
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 28 * 10^-9 (EN ISO 13849)
- Mission time: 20 years (EN ISO 13849)
- Supply voltage: 24 V DC (19.2 V to 28.8 V)
- Power consumption: ≤ 0.8 A
- Output type: PNP semiconductor, short-circuit protected
- Protection class: III (IEC 61140)
- Enclosure rating: IP65 (EN 60529)
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -30 °C to +70 °C
- Vibration resistance: 5 g, 10 Hz to 55 Hz
- Shock resistance: 10 g, 16 ms
- Dimensions (H x L x W): 55mm x 150mm x 52mm
- Weight: 1.2 kg
Key Features
- Receiver system part with 30 mm resolution
- Scanning range up to 21 m with 1,200 mm protective field height
- Response time: 13 ms without beam coding, 21 ms with beam coding
- Optical synchronization for reliable operation
- Type 4 safety rated (IEC 61496-1) with SIL 3 and PL e performance levels
- Functions include restart interlock, external device monitoring, beam coding, configurable status output, sender test, and configurable scanning range
- Supports safe SICK device communication via EFI and muting functions
- Interfaces include Hirschmann male connector M26 (12-pin), female M12 (5-pin) extension, and M8 (4-pin) configuration connectors
- 7-segment display and LEDs for status indication
- Housing made of aluminum alloy with powder coated surface and polycarbonate scratch-resistant front screen
- Protection class III with 24 V DC supply voltage and low power consumption
- IP65 rated enclosure for harsh environments
- Wide ambient operating temperature range from -30 °C to +55 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with safety light curtain systems and electrical safety standards.
Applications
- Industrial safety light curtain applications
- Machine safeguarding and access protection
- Automation and manufacturing safety systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption reduces energy usage
- Durable materials and robust design extend product lifespan
- Complies with RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK M40E-66A323RB0 Safety Light Curtain Receiver is available for immediate purchase, ideal for industrial safety and machine safeguarding applications.
