Safety Light Curtain Sender M40S-66A303AA0 | 30 mm Resolution | 21 m Scanning Range | IP65 Rated | by SICK
The M40S-66A303AA0 Safety Light Curtain Sender is designed for industrial safety applications, featuring a 30 mm resolution and a scanning range of up to 21 meters. With its robust aluminum housing and IP65 rating, it ensures reliable operation in hazardous environments, making it ideal for protecting personnel in manufacturing and processing plants.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Safety Light Curtain Sender, Industrial Safety Sensor, M40S Safety Sensor
Technical Specifications
- Resolution: 30 mm
- Scanning range: 21 m
- Protective field height: 1,200 mm
- Synchronization: Optical
- Safety type: Type 4 (IEC 61496-1)
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 28 * 10^-9 (EN ISO 13849)
- Mission time: 20 years (EN ISO 13849)
- Safe state on fault: At least one OSSD OFF
- Connection type: Hirschmann male connector M26, 12-pin
- Configuration: Via software with female M8, 4-pin connector
- Protection class: III (IEC 61140)
- Supply voltage: 24 V DC (19.2 V ... 28.8 V)
- Power consumption: ≤ 0.3 A
- Housing material: Aluminum alloy ALMGSI 0.5 with powder coating
- Front screen: Polycarbonate with scratch-resistant coating
- Enclosure rating: IP65 (EN 60529)
- Operating temperature: -30°C to +55°C
- Storage temperature: -30°C to +70°C
- Vibration resistance: 5 g, 10 Hz to 55 Hz
- Shock resistance: 10 g, 16 ms
- Wavelength: 850 nm
- Dimensions (H x L x W): 55mm x 150mm x 52mm
- Weight: 1.5 kg
Key Features
- Type 4 safety light curtain sender with 30 mm resolution
- Scanning range up to 21 meters with 1,200 mm protective field height
- Optical synchronization for reliable operation
- Safety integrity level SIL 3 and Category 4 compliance
- Configurable scanning range and safe device communication
- Functions include restart interlock, external device monitoring, beam coding, and muting
- Robust aluminum alloy housing with powder coating and scratch-resistant polycarbonate front screen
- IP65 rated enclosure for protection against dust and water
- Wide ambient operating temperature range from -30°C to +55°C
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with industrial safety systems and electrical standards to ensure compliance and optimal safety.
Applications
- Industrial safety for machinery and automation
- Protection of personnel in hazardous areas
- Use in manufacturing and processing plants
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Energy-efficient operation with low power consumption
- Durable materials and robust design reduce replacement frequency and waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK M40S-66A303AA0 Safety Light Curtain Sender is available for immediate purchase, ideal for industrial safety and automation applications.
