Safety Limit Switch i150-RP313 | 3 N/C & 1 N/O Contacts | IP65 Rated | by SICK
The i150-RP313 Safety Limit Switch is designed for industrial safety systems, featuring 3 positive action normally closed contacts and 1 normally open contact for reliable actuation. With an IP65 rated enclosure, it ensures protection against dust and water, making it ideal for machinery safety interlocks and automation equipment monitoring. Built to last with a mechanical life of 1 million cycles, this switch operates effectively in temperatures ranging from -25°C to +80°C.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Safety limit switch, Industrial safety switch, Positive action switch, SICK safety interlock
Technical Specifications
- Positive action N/C contacts: 3
- N/O contacts: 1
- Actuation force: 125 N at 300 mm deflection
- Actuation frequency: up to 3600 operations per hour
- Safe state in fault: No internal fault detection; relies on external safety logic
- Connection type: Cable gland, 3 x M20
- Conductor cross section: up to 1.5 mm²
- Usage category: AC-15/DC-13 (IEC 60947-5-1)
- Rated operating current: 3 A (240 V AC), 2 A (24 V DC)
- Rated insulation voltage Ui: 250 V
- Rated impulse withstand voltage Uimp: 2500 V
- Short-circuit protection: T6
- Switching voltage: ≥ 5 V DC
- Switching current: 5 mA at 5 V DC
- Housing material: Die cast lightweight metal with varnished surface
- Mechanical life: 1 million switching cycles
- Enclosure rating: IP65
- Operating temperature range: -25°C to +80°C
- Dimensions (H x L x W): 85mm x 203mm x 69mm
- Weight: 0.84 kg
Key Features
- 3 positive action normally closed (N/C) contacts and 1 normally open (N/O) contact
- Slow action switching element for reliable operation
- Rated operating current: 3 A (240 V AC), 2 A (24 V DC)
- Mechanical life of 1 million switching cycles
- IP65 rated enclosure for dust and water protection
- Operating temperature range from -25°C to +80°C
- Cable gland connection with 3 x M20 entries
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure compliance with safety standards and proper integration into safety systems.
Applications
- Industrial safety systems requiring reliable switch actuation
- Machinery safety interlocks
- Automation equipment safety monitoring
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and waste
- High reliability minimizes downtime and resource consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK i150-RP313 Safety Switch is available for immediate purchase, ideal for industrial safety and automation applications.
