Safety Mod Cat.3 48VAC | Emergency Stop Relay | DIN Rail Mountable | Reliable Machine Stop | @Pack of 1 | by Clipsal
The Safety Mod Cat.3 48VAC is a robust emergency stop safety relay designed for industrial machinery safety circuits. Operating at 48V AC, it features 2 NO + 1 NC relay outputs and is DIN rail mountable for easy installation. Ideal for automation panels and manufacturing plants, this relay ensures reliable machine stops in hazardous situations, enhancing workplace safety and compliance with stringent safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Safety Mod Cat.3 48VAC | Emergency Stop Relay | DIN Rail Mountable | Reliable Machine Stop | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHXPSAC1321
Alternatively Known As: Emergency Stop Safety Relay, XPSAC1321, Safety Relay Module 48VAC, Cat.3 Safety Module, Schneider XPSAC1321
Technical Specifications
- Supply voltage: 48V AC
- Safety category: Cat.3 (EN/ISO 13849-1)
- Relay outputs: 2 NO + 1 NC
- Mounting: DIN rail
- Operating temperature: -25°C to +55°C
- Response time: < 30 ms
- LED status indicators
- Conforms to IEC/EN 60204-1, IEC/EN 60947-5-1
- Dimensions (H x L x W): 99mm x 114mm x 22.5mm
- Weight: 0.25 kg
Key Features
- Category 3 safety relay module for emergency stop applications
- Operates at 48V AC
- Ensures reliable machine stop in hazardous situations
- DIN rail mountable for easy installation
- Meets stringent safety requirements for industrial environments
Professional Installation Requirements
- Installation must be performed by a qualified electrician or automation technician familiar with safety relay circuits and local safety standards.
Applications
- Industrial machinery safety circuits
- Emergency stop systems
- Automation panels
- Manufacturing plants
- Conveyor systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Enhances workplace safety, reducing risk of accidents and environmental hazards
- Supports compliance with safety regulations, promoting responsible industrial operations
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Safety Mod Cat.3 48VAC SCHXPSAC1321 is available for immediate purchase. Ideal for industrial emergency stop and safety circuit applications.
