Safety Module 1 Function | Cat 3 PL d/SIL CL2 | 24 VDC by Clipsal
Safety module with 1 function and Cat 3 PL d/SIL CL2 rating—ideal for industrial emergency stop and switch monitoring. Built for manufacturing environments, with easy connections and reliable safety compliance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Modicon TM3, Safety module, 1 Function, Cat 3 PL d/SIL CL2 (screw) 24 VDC
Brand: Clipsal
SKU: TM3SAC5R
Alternatively Known As: TM3 Safety Module, Emergency Stop Module, Safety Relay Module
Technical Specifications
- Power consumption: 3.6 W at 24 V DC.
- IP Rating: IP20.
- Operating temperature: -10 to 55 °C.
- Relative humidity: 10 to 95 % without condensation.
- Safety level: PL d/category 3, SIL CL2.
- Dimensions (H x L x W): 94mm x 73mm x 43.7mm
- Weight: 0.19 kg
Key Features
- 1-channel and 2-channel emergency stop monitoring.
- Monitoring of movable guards with automatic start.
- Captive screw clamp terminals for easy connections.
Professional Installation Requirements
- Professional installation is recommended for optimal safety and compliance.
Applications
- Industrial: Emergency stop and switch monitoring in manufacturing and automation environments.
Standards & Compliance
- Complies with ISO 13849-1:2008 and IEC 62061:2005.
Environmental Benefits
- Complies with environmental regulations and standards.
Warranty Information
Standard warranty applies.
Available Now
The Clipsal Modicon TM3 Safety Module is available now for immediate purchase. Ideal for industrial applications requiring safety monitoring.
