Safety Relay 24VAC/DC | 1NC/LC-IN 2NO-SFTY | Rail Mount by NHP

BRAND: NHP
SKU: 440RN23123
$321.50 List price: $426.90
+ −
30 Days Return Delivery Options
Safety relay with 24VAC/DC voltage and 1NC/LC-IN 2NO-SFTY outputs—ideal for industrial and commercial safety monitoring. Built for high performance, with rail mounting for easy installation and compliance with safety standards.

Product Name/Title: AB 440R MSR Safety Relay 24VAC/DC 1NC/LC-IN 2NO-SFTY MM

Brand: NHP

SKU: 440RN23123

Alternatively Known As: Safety Relay, MSR Relay, Monitoring Relay

Technical Specifications
  • Rated operation current (IE): 6 A
  • Rated operation current at AC 15 (230 V): 6 A
  • Rated operation current at DC 13 (24 V): 3 A
  • Voltage type for actuating: AC/DC
  • Control supply voltage (US) at DC: 24 V
  • Control supply voltage (US) at AC (50 Hz): 24 V
  • Number of outputs safety-related undelayed with contact: 2
  • Max shock acceleration: 10 g
  • Max vibration displacement (pk-pk): 0.35 mm
  • Max vibration frequency operational: 55 Hz
  • Ambient temperature during operating: -5 to 55 °C
  • Dimensions (H x L x W): 75mm x 110mm x 22.5mm
  • Weight: 0.16 kg
Key Features
  • Safety category according to EN ISO 13849-1: Category 4
  • Performance level according to EN ISO 13849-1: Level e
  • IP40 protection degree for the relay and IP20 for terminals
  • Rail mounting capability for easy installation
Professional Installation Requirements
  • Professional installation by a qualified technician is recommended for optimal safety and compliance.
Applications
  • Industrial: Safety monitoring in machinery and equipment
  • Commercial: Safety systems in buildings and facilities
Standards & Compliance
  • Complies with AS/NZS 4801 for Occupational Health & Safety Management Systems.
Environmental Benefits
  • Designed to enhance safety in operational environments, reducing the risk of accidents.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 440R MSR Safety Relay is available now for immediate purchase. Ideal for safety monitoring in industrial and commercial applications.

Non-Returnable & Non-Cancellable

440RN23123-AU-MSR-Safety-Relay-Datasheet.pdf (440RN23123-AU-MSR-Safety-Relay-Datasheet.pdf, 280 Kb) [Download]
